SLOTTED CHEESE HEAD SCREW SERIES 536
• Made from PA-66 • Colour: natural • Meets dimensional tolerances of: ISO 1207, NFE 25-127, DIN 84 • Metric screw thread AxB Examples of use Dimensions Dimensions in mmPrices in Sterling per unit
Article number GramCol A B C D E F Price Per Price Per Price Per
536 0090 000 02 0.06 M3 0.5 4 5.5 2 0.8 33,04 1000 21,39 500 11,44 250 536 0095 000 02 0.88 M3 0.5 5 5.5 2 0.8 33,04 1000 21,39 500 11,44 250 536 0100 000 02 0.08 M3 0.5 6 5.5 2 0.8 33,04 1000 21,39 500 11,44 250 536 0105 000 02 0.09 M3 0.5 8 5.5 2 0.8 33,04 1000 21,39 500 11,44 250 536 0110 000 02 0.11 M3 0.5 10 5.5 2 0.8 33,04 1000 21,39 500 11,44 250 536 0115 000 02 0.12 M3 0.5 12 5.5 2 0.8 33,04 1000 21,39 500 11,44 250 536 0120 000 02 0.14 M3 0.5 16 5.5 2 0.8 33,04 1000 21,39 500 11,44 250 536 0125 000 02 0.16 M3 0.5 20 5.5 2 0.8 34,58 1000 22,39 500 11,97 250 536 0130 000 02 0.20 M3 0.5 25 5.5 2 0.8 36,01 1000 23,32 500 12,47 250 536 0135 000 02 0.22 M3 0.5 30 5.5 2 0.8 40,29 1000 26,09 500 13,95 250 536 0140 000 02 0.25 M3 0.5 35 6 2.4 1 50,98 1000 33,01 500 17,65 250 536 0145 000 02 0.00 M3 0.5 40 6 2.4 1 53,11 1000 34,39 500 18,39 250 536 0150 000 02 0.16 M4 0.7 6 7 2.6 1.2 33,64 1000 21,78 500 11,64 250 536 0155 000 02 0.18 M4 0.7 8 7 2.6 1.2 33,64 1000 21,78 500 11,64 250 536 0160 000 02 0.20 M4 0.7 10 7 2.6 1.2 33,64 1000 21,78 500 11,64 250 536 0165 000 02 0.22 M4 0.7 12 7 2.6 1.2 33,64 1000 21,78 500 11,64 250 536 0170 000 02 0.27 M4 0.7 16 7 2.6 1.2 33,64 1000 21,78 500 11,64 250 536 0175 000 02 0.30 M4 0.7 20 7 2.6 1.2 34,93 1000 22,62 500 12,09 250 536 0180 000 02 0.40 M4 0.7 25 7 2.6 1.2 36,36 1000 23,54 500 12,59 250 536 0185 000 02 0.41 M4 0.7 30 7 2.6 1.2 37,78 1000 24,46 500 13,08 250 536 0190 000 02 0.54 M4 0.7 40 7 2.6 1.2 53,97 1000 34,94 500 18,69 250 536 0195 000 02 0.35 M5 0.8 6 8.5 3.3 1.2 53,25 1000 34,48 500 18,44 250 536 0200 000 02 0.35 M5 0.8 8 8.5 3.3 1.2 49,55 1000 32,09 500 17,16 250 536 0205 000 02 0.35 M5 0.8 10 8.5 3.3 1.2 49,55 1000 32,09 500 17,16 250
All prices are indicative. Check www.skiffy.com for our current prices and more information about materials and colours . FAX: 01902-894661 · TEL: 01902-894658 · WWW.SKIFFY.COM
