• Made from Nylon 66 compound with carbon fibre and PTFE • Colour: black • Improved mechanical characteristics and reduced wear • Maximum rotating speed 0.9 m/s • Friction coefficient 0.11 (statical) • Bearing house to be tolerance H7, shaft h6 Examples of use Dimensions Dimensions in mm Prices in Sterling per unit
Article number GramCol A B C D E F Price Per Price Per Price Per
103 5020 114 42 0.12 6.0 8.0 4.0 149,14 1000 92,84 500 24,23 100103 5040 114 42 0.17 6.0 8.0 6.0 152,31 1000 94,81 500 24,75 100103 5060 114 42 0.23 6.0 8.0 8.0 155,49 1000 96,79 500 25,27 100103 5080 114 42 0.29 6.0 8.0 10.0 158,65 1000 98,77 500 25,78 100103 5100 114 42 0.20 8.0 10.0 5.5 165,00 1000 102,71 500 26,81 100103 5120 114 42 0.28 8.0 10.0 7.5 168,18 1000 104,69 500 27,33 100103 5140 114 42 0.37 8.0 10.0 10.0 174,53 1000 104,28 500 27,49 100103 5160 114 42 0.56 8.0 10.0 15.0 184,04 1000 109,97 500 28,98 100103 5180 114 42 0.27 10.0 12.0 6.0 180,87 1000 108,07 500 28,49 100103 5200 114 42 0.41 10.0 12.0 9.0 187,22 1000 111,86 500 29,49 100103 5220 114 42 0.54 10.0 12.0 12.0 196,73 1000 117,55 500 30,98 100103 5240 114 42 0.68 10.0 12.0 15.0 203,08 1000 65,24 250 19,90 50103 5260 114 42 0.48 12.0 14.0 9.0 272,89 1000 84,60 250 24,09 50103 5280 114 42 0.64 12.0 14.0 12.0 282,41 1000 87,54 250 24,92 50103 5300 114 42 0.80 12.0 14.0 15.0 291,93 1000 90,50 250 25,76 50103 5320 114 42 1.07 12.0 14.0 20.0 307,79 1000 95,42 250 27,17 50103 5340 114 42 0.93 14.0 16.0 15.0 298,28 1000 92,46 250 26,32 50103 5360 114 42 1.23 14.0 16.0 20.0 317,32 1000 98,37 250 28,01 50103 5380 114 42 0.79 15.0 17.0 12.0 307,79 1000 95,42 250 27,17 50103 5400 114 42 0.99 15.0 17.0 15.0 320,49 1000 99,35 250 28,28 50103 5420 114 42 1.32 15.0 17.0 20.0 339,53 1000 105,26 250 29,96 50103 5440 114 42 0.84 16.0 18.0 12.0 310,97 1000 96,40 250 27,44 50103 5460 114 42 1.05 16.0 18.0 15.0 323,66 1000 100,34 250 28,56 50103 5480 114 42 1.40 16.0 18.0 20.0 342,70 1000 106,24 250 30,25 50
All prices are indicative. Check www.skiffy.com for our current prices and more information about materials and colours . WWW.SKIFFY.COM · TEL: 01902-894658 · FAX: 01902-894661
