• Made from PA-66 • Colour: natural • Perfectly suitable for soundless hinging, low R.P.M. machines etc. • Suitable for DIN h6-H7 fitting • After assembly bearing clearance about 1% of the shaft diameter • Insensitive to dirt, weather influences and most chemicals Examples of use Dimensions Dimensions in mm Prices in Sterling per unit
Article number GramCol A B C D E F Price Per Price Per Price Per
103 0812 000 02 0.68 8.0 12.0 10 74,11 1000 47,99 500 13,52 100103 0814 000 02 1.11 8.0 14.0 10 92,08 1000 59,62 500 16,80 100103 1012 000 02 0.37 10.0 12.0 10 65,13 1000 42,17 500 11,89 100103 1014 000 02 0.87 10.0 14.0 10 78,61 1000 50,90 500 14,35 100103 1016 000 02 1.38 10.0 16.0 10 159,45 1000 99,26 500 25,91 100103 1214 000 02 0.45 12.0 14.0 10 65,13 1000 42,17 500 11,89 100103 1216 000 02 0.97 12.0 16.0 10 94,32 1000 58,71 500 15,33 100103 1218 000 02 2.20 12.0 18.0 14 130,26 1000 81,08 500 21,17 100103 1520 000 02 2.27 15.0 20.0 15 132,50 1000 82,48 500 21,53 100103 1522 000 02 3.38 15.0 22.0 15 161,70 1000 100,66 500 26,27 100103 1525 000 02 5.26 15.0 25.0 15 238,06 1000 142,24 500 37,49 100103 1620 000 02 1.88 16.0 20.0 15 123,52 1000 76,89 500 20,07 100103 1622 000 02 2.99 16.0 22.0 15 177,43 1000 110,44 500 28,83 100103 1624 000 02 4.28 16.0 24.0 15 231,32 1000 138,21 500 36,43 100103 2024 000 02 2.34 20.0 24.0 15 145,98 1000 90,87 500 23,72 100103 2025 000 02 2.88 20.0 25.0 15 175,18 1000 109,05 500 28,47 100103 2026 000 02 4.88 20.0 26.0 20 226,83 1000 135,53 500 35,72 100103 2028 000 02 6.71 20.0 28.0 20 278,49 1000 166,39 500 43,86 100
Article numberAll prices are GROSS xxx xxxx xxx XX Article material, see page for discounts see payment conditions material information
All prices are indicative. Check www.skiffy.com for our current prices and more information about materials and colours . FAX: 01902-894661 · TEL: 01902-894658 · WWW.SKIFFY.COM
