RIBBED INSERT SERIES 063
• Made from PA-6, with metric screw head • Colour: black • Perfect supplement to series 148, adjustable foot • Available for round and square tubes • Maximum static axial load (with steel screw): 300 kg Examples of use Dimensions Dimensions in mmPrices in Sterling per unit
Article number GramCol A B C D E F Price Per Price Per Price Per
063 0050 114 01 5.08 20 21.5M8F1 135,27 1000 84,20 500 21,98 100063 0055 114 01 5.80 22 21.5M8F1 140,53 1000 87,48 500 22,84 100063 0060 114 01 8.70 25 21.5M8F1 160,60 1000 99,97 500 26,10 100063 0065 114 01 12.00 30 21.5M8F1 198,60 1000 118,66 500 31,28 100063 0070 114 01 16.53 35 29M8F1 344,15 1000 106,68 250 30,37 50063 0150 114 01 4.26 20 21.5M10F1 135,27 1000 84,20 500 21,98 100063 0155 114 01 5.30 22 21.5M10F1 140,53 1000 87,48 500 22,84 100063 0160 114 01 7.45 25 21.5M10F1 160,60 1000 99,97 500 26,10 100063 0165 114 01 12.16 30 21.5M10F1 198,60 1000 118,66 500 31,28 100063 0170 114 01 16.61 35 29M10F1 339,85 1000 105,35 250 29,99 50063 0550 114 01 4.40 22 21.5M8F2 161,80 1000 100,72 500 26,29 100063 0555 114 01 6.60 25 21.5M8F2 197,17 1000 117,80 500 31,05 100063 0560 114 01 9.84 30 21.5M8F2 242,09 1000 144,65 500 38,13 100063 0565 114 01 11.30 32 29M8F2 254,76 1000 81,84 250 24,96 50063 0570 114 01 13.45 35 29M8F2 307,10 1000 95,20 250 27,10 50063 0575 114 01 18.26 40 29M8F2 437,35 1000 127,93 250 35,43 50063 0650 114 01 4.00 22 21.5M10F2 158,45 1000 98,63 500 25,75 100063 0655 114 01 5.79 25 21.5M10F2 185,46 1000 110,81 500 29,21 100063 0660 114 01 8.90 30 21.5M10F2 228,00 1000 136,23 500 35,91 100063 0665 114 01 10.70 32 29M10F2 248,31 1000 79,77 250 24,33 50063 0670 114 01 13.10 35 29M10F2 301,36 1000 93,42 250 26,60 50063 0675 114 01 18.40 40 29M10F2 427,55 1000 125,06 250 34,63 50
All prices are indicative. Check www.skiffy.com for our current prices and more information about materials and colours . WWW.SKIFFY.COM · TEL: 01902-894658 · FAX: 01902-894661
