| | | MARIN E PRODUCT DATA SHEET OEM: 4902-4 202 AFTERMARKET: 4902-4 21 2 | | |
| | | |
| | | The most advance system available, this fully-automatic, quit unit pumps tasteless, odorless water smoothly and consistently. Corrosion resistance and NSF certified tank. | | |
| | | |
| | | TYPICAL APPLICATIONS Multi-fixture marine fresh water installations. Other uses may included 12V DC pressurized water systems in cabins This pump may be used for general water transfer. For other applications, contact SHURflo. | | |
| | | |
| | | PUMP Type: Ports: Liquid: Prime: Inlet PSI: Run Dry: | | |
| | | 4 Chamber Diaphragm 1/2"-14 NPSM-Male. 130 °F [54 °C] Max 6 feet [1.82 M] 30 PSI [2.1 Bar] Max Yes | | |
| | | |
| | | |
| | | ELECTRICAL Motor: Protection: Leads: Fuse: Control: MATERIALS | | |
| | | 14 AWG, 16" [40 cm] Red +, 13" [33 cm] Black - 15 Amp Recommended Adjustable Switch. Shut-Off 45 PSI [3.1 Bar] ± 5 PSI [0.4 Bar] Restart 25 PSI [1.8 Bar] ± 5 PSI [0.4 Bar] | | |
| | | |
| | | Nylon EPDM Santoprene Stainless Steel | | |
| | | Repair Kits | | |
| | | |
| | | |
| | | APPROVALS Ignition Protected, CE, ISO 8846 WARRANTY 3 Year Limited Warranty See SB-1041 & SB-1050 For Full Warranty Details | | |
| | | |
| | | SHIPPING Net Weight (Boxed): Carton Weight: Carton Size: | | |
| | | Lb[Kg] each each, Lb [ Kg] "L x "W x "H [cm x cm x cm] | | |
| | | | | | | | | | | Number | Description | Part Number | | | | 1 | Switch Assy | 94-668-00 | | | | 2 | Upper Hsg | 94-670-01 | | | | 3 | Valve Assy | 94-669-00 | | | | 4 | Drive Assy | 94-670-00 | | | | 5 | Motor | 77-013-17 | | | | | | | | | | |
| | | |
| | | |
| | | RELATED DOCUMENTS Catalog: Installation Manual: Maintenance: Applications Spec Guide: Warranty: | | |
| | | MS-030-084 911-740 911 -740 MS-020-005 SB-1041 / SB-1050 | | |
| | | |
| | | |
| | | SHURflo | | |
| | | |
| | | |
| | | | PuclEljït WftWt | | | |
| | | |
| | | FC649Q2-4Q2 | | |
| | | Rev QQÌIQQÌ | | JUy07 | |
| | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
