ProMetrix
TM Rapid Market Response
• Many components are pre-machined and stocked to provide quick delivery. • Proven and pre-engineered spindle designs take the guesswork out of your spindle selection process.• ProMetrix’s computer-directed design process allows for rapidprototyping and eliminates the need to check and recheck drawings.
The ProMetrix™Design System Addresses Your Customized Spindle Needs
ProMetrix With the proprietary design system developed for design system. The program then
modifies the spindle to your exact
specifications and generates several
hundred other parameters to define
the spindle geometry. CAD drawings
can be e-mailed to you for review
and approval. ProMetrix ,you get a spindle customized to your requirements with a delivery time that meets your requirements. To create your customized ProMetrix spindle, youspecify key parameters: housing width and length,
nose extension, spindle nose configuration and
mounting bolt pattern are examples of key
parameters. A SETCO engineer enters
your parameters into the 1-800-543-0470.
Technical Assistance
This catalog contains reference information including charts, dimensional
drawings and design data to assist you in selecting the spindle that meets
your exact needs. A certified outline drawing is supplied with each order. If you need more information or would like assistance with an application challenge, contact SETCO’s Design Team at
