Super Select DS
Slides for EveryApplication
Type 4304MYBelt Driven
Milling spindle with 3 HP“C” flange mounted motor, belt and pulleys, belt
guard, and belt tensioning. Mounted to a DS8 Slide
with ground thread ballscrew and preloaded ballnut,
accordion way covers and 2:1 belt drive package
with
servomotor.
DS12 Slide mountedto a vertical angle
plate with complete
motor drive package
for
spindles. Both
saddles are manually
positioned with
separate feedscrews
and ratchet handles.
DS12 slide with dual saddlesand feedscrews to position
spindles for grinding of motor
stator “halves” as stock is fed
between wheels. The right angle
attachment puts handwheel
where most convenient or
accessible to operator.
Motorized Milling SpindleAssembly mounted to a 3 axis slide DS 10 withservomotor drive. Customerprovided CNC control.Each axis also includesaccordion way coversand rolled threadballscrew.
Photo #3483M
Photo #3894M
Photo #3268M
