Servomech screwjacks
Construction and featurespages1-3Performance summarypages4-5
Screwjack selectionpages 6-17
Ordering and specificationpages 18-19
Dimensionspages 20-23
Options and featurespages 24-32
Installation - Maintenance - Lubricantspage 33Screwjack systemspages 34-35
Screw jacks check sheetpages 36-37
SUMMARY
★ forces from 5 kN to 350 kN ★ speeds up to 150 mm/s ★ maximum duty cycle 30% ★ free shaft or motorised input ★ ac or
dc motors ★ travelling nut or travelling screw
Choose series MA for:– high duty cycles– higher linear speeds
– input speeds above1500 r/min– long life oil lubricant
– 1, 2 or 3 start threads
– optional ballscrewsChoose series SJ for:– lower duty cycles– lower costs
– compact dimensions
– easy mounting
– long life greaselubricant
Founded in 1989, Servomech has become a leading forceworldwide for industrial linear motion. The Servomech
product range covers both actuators and screwjacks with
max. forces from 500 N to 350 kN. Screwjacks make up the
heavier end of this range with housing designs either in
monobloc aluminium or cast iron. Quality construction suits
long life in industrial applications. ©Copyright SERVOMECH 2004
