Servomech
® ATL series: Worm gear drive and acme leadscrewBSA series:Worm gear drive and
ball screw
UAL series:
Timing belt and acme leadscrewUBA series:Timing belt and ball screw
ATL and BSA Series SERVOMECH Actuators Input drives Worm gear drive Timing belt drive
Leadscrew t y pe Leadscrew t yp e Acme screw Ball screw Acme screw Ball screw A TL series BSA series UAL series UBA series ATL 10ATL 20ATL 50ATL 25ATL 63ATL 30ATL 80
ATL 40 BSA 10BSA 20BSA 50BSA 25BSA 63BSA 30BSA 80BSA 40 UAL 0UAL 1UAL 2
UAL 3UAL 4 UBA 0UBA 1UBA 2UBA 3
UBA 4 ATL 10 and BSA 10:Compact linear actuator with integral electric motor, available with AC 3-phases, AC 1-phase, DC24 V or 12 V
electric motors with or without brake. ATL 20 – 25 – 30 – 40 and BSA 20 – 25 – 30 – 40:4 sizes with monoblock housing in hardened aluminium alloy.Available in 4 different versions, see page 91.
- Vers.1single input shaft- Vers.2double input shaft- Vers.3input motor flange European standard IEC B14
- Vers.4input motor flange European standard IEC B14 and extended input shaft
Electric motors available: AC 3-phases, AC 1-phase, DC 24 V or 12 V, with or without brake. ATL 50 – 63 – 80 and BSA 50 – 63 – 80:3 sizes with monoblock housing in spheroidal graphite cast iron GS 500.Available in 6 versions: 4 as the previous ones but with motor flange IEC B5 – 2 with motor flange
adapter + coupling (see page 92). Electric motors available: AC 3-phases with or without brake.UAL and UBA Series UAL 0 and UBA 0:Compact linear actuator with integral electric motor.Available only with
Dc motor manufacturer 24 V or 12 V, with or without brake. UAL 1 – 2 – 3 – 4 and UBA 1 – 2 – 3 – 4:Integral electric motors AC 3-phase, AC 1-phase or DC, available with or without brake.Motors with European standard frame size IEC B14.
– 3 –
