Specifications – TLF Series

Tube Shell Shipping Part Model No. Shell Design Tube Design Material Material Area Weight Number TLF-4225 450 psi @ 650ºF 5000 psi @ 1000ºF 316/316L SS 304 SS 2.4 ft
2 12 lbs 7-00686A 31 bar @ 345ºC 345 bar @ 540ºC 1/4" O.D. x 0.049" AW 0.22 m
2 5.5 kg TLF-4225U 450 psi @ 650ºF 4400 psi @ 1000ºF 316/316L SS 304 SS 2.4 ft
2 12 lbs 7-00686B 31 bar @ 345ºC 303 bar @ 540ºC 1/4" O.D. x 0.049" AW 0.22 m
2 5.5 kg TLF-42B5 450 psi @ 650ºF 5000 psi @ 1100ºF Alloy (Inconel
® ) 625 304 SS 2.4 ft
2 14 lbs 7-00686L 31 bar @ 345ºC 345 bar @ 593ºC 1/4 " O.D. x 0.035" AW 0.22 m
2 6.5 kg TLF-42B5U 450 psi @ 650ºF 5000 psi @ 1100ºF Alloy (Inconel
® ) 625 304 SS 2.4 ft
2 12 lbs 7-00686P 31 bar @ 345ºC 345 bar @ 593ºC 1/4" O.D. x 0.035" AW 0.22 m
2 5.5 kg TLF-44B5 150 psi @ 250ºF 5000 psi @ 1100ºF Alloy (Inconel
® ) 625 Cupronickel/ 2.4 ft
2 14 lbs 7-00693E 10 bar @ 121ºC 345 bar @ 593ºC 1/4" O.D. x 0.035" AW Monel
® 0.22 m
2 6.5 kg
NOTE:• U in model number denotes ASME stamped model. • Canadian Registration Number available for ASME stamped models only. Consult factory for CRN and other options and information.• Vessels are exempt from CE marking per PED 97/23/EC. Vessels are below or equal to the limits set forth in Article 3, Sections 1.1, 1.2, 1.3 and Section 2 as applicable, and are designed and manufactured in accordance with sound engineering practice (meets the general requirements of the ASME Section VIII, Division 1, Professional boiler And Pressure Vessel Code). Nameplate will bear the name of Sentry Equipment Corp and safety instructions will be included per Article 3, Section 2. It is solely the responsibility of the end-user, through its own analysis and testing, to select products and materials suitable for their specific application requirements, ensure they are properly installed, safely applied, properly maintained, and limit their use to their intended purpose. Improper selection, installation, or use may result in personal injury or property damage.

SENTRY EQUIPMENT CORP

For further information, contact: PO Box 127Oconomowoc, WI 53066 USAPhone: 262-567-7256 Fax: 262-567-4523 E-mail: sales@sentry-equip.com Website: www.sentry-equip.com
