| | | Automatic Cycle Time: Select a cycle lime on adjustable delay timer that will provide adequate sample composite for professional container in use. DO NOT overfill container. Sample delivery is charted for professional samplers with 3cc liquid volumetric displacement per cycle. Partial chart shown below. Cycle time * is a combination of time to fully extend plunger into product line, then completely retract and discharge sample collected. | | |
| | | |
| | | SAMPLE COMPOSITE VOLUME | | |
| | | |
| | | TOTAL SAMPLE (CC) AT 3CC PER CYCLE | | |
| | | | | | | | | | | | | | | CYCLE TIME* | TOTAL SAM | PLING TIM | | | | | S Min | 10 Min | 30 Min | 1 Hour | 8 Hours | 24 Hours | | | | 5 sec | 180 | 360 | 1080 | 2160 | 17.230 | 51840 | | | | 10 sec | 90 | 180 | 540 | 1080 | 8640 | 25,920 | | | | 15 sec | 60 | 120 | 360 | 720 | 5760 | 17,280 | | | | 20 sec | 45 | 90 | 270 | 540 | 4320 | 12,960 | | | | 30 sec | 30 | 60 | 1B0 | 360 | 28S0 | 8640 | | | | 60sec | 15 | 30 | 90 | 180 | 1440 | 4320 | | | | 120 sec | 6 | 15 | 45 | 90 | 720 | 2160 | | | | 300 sec | 3 | 6 | 16 | 36 | 288 | 864 | | | | 480 sec | - | 3 | 9 | 21 | 180 | 540 | | | | 600 sec | - | 3 | 9 | 18 | 144 | 432 | | | | | | | | | | | | | | |
| | | |
| | | TOTAL SAMPLE (OZ) AT 3CC PER CYCLE | | |
| | | |
| | | | | | | | | | | | | | | CYCLE TIME* | TOTAL SAM | PLING TIM | | | | | 5 Min | 10 Min | 30 Min | 1 Hour | 8 Hours | 24 Hours | | | | 5 sec | 6.08 | 12.17 | 36.50 | 73.00 | 584.06 | 1752.19 | | | | 10 sec | 3.04 | 6.011 | 18.25 | 36.50 | 292.03 | 37G.10 | | | | 15 sec | 2.03 | 4.06 | 12.17 | 24.34 | 194.69 | 584.06 | | | | 20 sec | 1.52 | 3.04 | 9.13 | 18.25 | 146.02 | 438.05 | | | | 30 sec | 1.01 | 2.03 | 6.08 | 12.17 | 97.34 | 292.03 | | | | 60 sec | 0.51 | 1.0* | 3.04 | 6.08 | 48.67 | 146.02 | | | | 120 sec | 0.20 | 0.51 | 1.52 | 3.04 | 24.34 | 73.00 | | | | 300 sec | 0.10 | 0.20 | 0.61 | 1.22 | 9.73 | 29.20 | | | | 480 sec | - | 0.10 | 0.30 | 0.71 | 6.08 | 18.25 | | | | 600 sec | - | 0.10 | 0.30 | 0.61 | 4.87 | 14.60 | | | | | | | | | | | | | | |
| | | |
| | | To convert cubic centimeters to fluid ounces, multiply by .0338. There are approximately 30cc (29.5735) to one fluid ounce, 128 fluid ounces to one U.S. gallon. * CYCLE TIME = CC PER CYCLE X TOTAL SAMPLING TIME fSECl TOTAL SAMPLE (CC) | | |
| | | |
| | | ■ CYCLE TIME (SEC) = EXTEND TIME + RETRACT TIME | | |
| | | |
| | | | | | | | | | | | | | | | | | | | |
