| | | 4-20mA vibration transducer, up to 50mm/s range, +I20°C operation and broadband velocity output performance 2.5Hz - 6KHz. ATEX approval. The PZDC series of Vibration transducers are compact and robust sealed instruments providing a process output of 4-20mA proportional to RMS velocity vibration. The series is designed for applications requiring direct integration in to SCADA systems (PLC/DCS) providing an extremely cost effective solution for measuring overall vibration performance. A simple two-wire loop signal proportional to current provides the electrical interface; the velocity vibration range is factory set between I5mm/s and 50mm/s as standard. Utilising Sensonics compression mode technology the sensors offer an extremely linear performance over the full dynamic range and accuracy to within a few percent. With ATEX approval across the PZDC range, the series is available in three packages to suit most applications including MIL connector and armoured cable options. Ruggedised with isolated/non-isolated armoured conduit and fully isolated versions are available (PZDC3) for use in harsh industrial environments where earth loops and interference are problematic. | | |
| | | |
| | | The PZDC Product Family Model No. I Mechan, | | |
| | | iterface Options Integral PTFE Cable Armoured Option MIL 2-pin Conn Waterproof PU option | | |
| | | Application | | |
| | | |
| | | |
| | | General Purpose Engines, Motors, Pumps, Fans Centrifuges PLC/DCS Intrinsically Safe | | |
| | | PZDC | | |
| | | |
| | | *s -ÇTXC ^1 | | |
| | | |
| | | |
| | | |
| | | Integral PTFE Cable Armoured Option Additional Accel (g) signal output | | |
| | | | | |
| | | General Purpose Engines, Motors, Pumps, Fans PLC/DCS Datacollectors | | |
| | | |
| | | |
| | | |
| | | Integral PTFE Cable Armoured Isolated Conduit Inner screen isolated from case | | |
| | | Heavy Industrial Motors , Pumps, Fans Low Profile PLC/DCS Intrinsically Safe | | |
| | | arac]:: | | |
| | | |
| | | |
| | | |
| | | Note:- The PZDC2 provides both a 4-20mA proportional to velocity vibration for the PLC interface as well as an acceleration output (100mV/g) for more detailed analysis on portable instrumentation | | |
| | | |
| | | 8 | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
