: A

EXTENSION CABLES

Available in various 'tuned' lengths up to 18m. With or without stainless steel ovcrbraid armouring.

Various connectors, oversheaths And sealing glands are available, and supplied fitted.

Ordering details appear on relevant probe data sheets

DRIVER UNITS

Compact design cither baseplate or DIN rail mounted

Robust connector supplied for convenient connection/disconnection

Electrically isolated case

Four connections per box required (■24V. OV. Signal and OV)

Operating temperature, -30°C to +90ⁿC Ordering details appear on relevant probe data sheets

PROBE HOLDER

Enables the replacement of probes without recaJibratio

• Available in aluminium alloy or stainless steel enclosure

• Internal adjustment of probe insertion depth

• Sealed at both cable and probes entry points

• Up to 300mm maximum Insertion depth

For details refer to data sheet L165

DRIVER HOUSING

9 Sheet steel enclosure with removable gland plates and lockable door

• Sealed to IP65

• Capacity (or 2. 4, 6 or 9 drivers

• Fully wired with terminal* fitted

For details refer to data sheet L166
