DRY MATERIAL FEEDING
Dry material feeding
and PREPARATION SYSTEMS
AND Preparation Systems
POWDER FEEDERS
Powder volumetric feeders are designed to provide a constant and accurate flow for any grains, fibers and powders. Powder
feeders are completely made in stainless steel SS304.
VG100
Construction Features
Hopper: It was two vertical walls ensure even flow of the products; available in 50
and 100 liters versions; optional: supplementary mixer or vibration; internal
polishing, level indicator.
Gearbox: motion transmission is carried out by a chain/pinion, which are connected
to metering helix and to agitator rotates; optional: FPM seals-ring.
Speed variator: (manual adjustement) it provides capacity control, when feeder is
running between 10 and 100% of maximum delivery; 3-phase motor, 0,18 kw,
insulation class F; optional: coaxial gear for constant feeding, gravitation indicator.
Metering helix: the accuracy depending from characteristics of products, from 0,5%
to 3%; optional: reinforced metering helix, solid metering helix, extended helix and
discharge tube.
OPTIONAL:
Thermostat resistance: to avoid product agglomeration, caused by humidity.
Dissolver: to ensure a perfect dilution of product in water, thanks to a specific design and
to a water-flow control.
03
Flow rate min. (l/h)
Flow rate max. (l/h)
Continuous Flow rate (l/h)
04
12
05
0,7
3,7
2,8
3
17
13
65
50
VG50
It is a simple and economical product, with a compact design, able to assure at the same time a constant and
accurate dosing; it can be used with powders, flakes and fibers that are not subject to agglomeration and so it does
not need to use the agitator rotates (example: polyelectrolyte).
OPTIONAL:
Thermostat resistance: to avoid product agglomeration, caused by wetness.
Plexiglas discharge: to canalize the product without useless wastages.
Dissolver: to ensure a perfect dilution of product in water, thanks to a specific design and to a water-flow control.
03
Flow rate min. (l/h)
Flow rate max. (l/h)
Continuous Flow rate (l/h)
innovation > technology > future
04
05
0,7
3,7
2,8
3
17
13
12
65
50
SEKO Asia Pacific SINGAPORE • SEKO China CHINA • SEKO do Brasil BRAZIL • SEKO Dosing
Systems USA • SEKO Deutschland GERMANY • SEKO France FRANCE • SEKO Iberica SPAIN
SEKO Italia ITALY • OOO SEKO RUSSIA • SEKO Northern Europe DENMARK • SEKO SIETA
ROMANIA • SEKO Southern Africa SOUTH AFRICA • SEKO UK UNITED KINGDOM
The technical data may be modified without notice.
The drawings and images are only indicative
www.seko.com
© seko spa / Printed in Italy /BRODRYUK 10.1
