table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:8.00pt "Arial", sans-serif; } .font1 { font:11.00pt "Arial", sans-serif; } .font2 { font:16.00pt "Arial", sans-serif; } .font3 { font:19.00pt "Arial", sans-serif; } .font4 { font:31.50pt "Arial", sans-serif; } Easyflow Variable area Flowmeter These flowmeters operate according to the variable area principle, where a float is suspended in upward flowing media in a tapered plastic tube. The vertical position of the float within the metering tube depends on the flowrate of the media. The metering tube is graduated in...

table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:8.00pt "Arial", sans-serif; } .font1 { font:11.00pt "Arial", sans-serif; } .font2 { font:16.00pt "Arial", sans-serif; } .font3 { font:19.00pt "Arial", sans-serif; } Easyflow Technical Data Diameter - Type 700 Range d25 (3/4"); d32 (1"); d40 (1 1/4"); d50 (1 1/2"); d63 (2"); d75 (2 1/2") - Type 750 d16 (3/8"); d20 (1/2"); d25 (3/4"); d 32 (1") Materials - Measuring tube Transparent PVC-U; Trogamid (PA); Polysulfon (PSU) - Float Stainless Steel 1.4571 (AISI 316 Ti); PP; Stainless Steel 1.4571 (AISI 316 Ti) + magnet;...

table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:8.00pt "Arial", sans-serif; } .font1 { font:11.00pt "Arial", sans-serif; } .font2 { font:16.00pt "Arial", sans-serif; } .font3 { font:19.00pt "Arial", sans-serif; } .font4 { font:31.50pt "Arial", sans-serif; } Easyflow Part List Description Material Quantity 5 Transparent PVC-U 1 Tube Trogamid (PA) 1 4 2 Polysulfon (PSU) Adjustable visual flow indicator PVDF 2 6 7.1 8 3 3* Floater wing PVDF 1 PVC-U 4 Nut PVC-C 2 PP Stainless Steel 2 Malleable Cast Iron PVC-U 1 PVC-C 5 End connector PP 2 2 Stainless Steel Malleable...

table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:8.00pt "Arial", sans-serif; } .font1 { font:11.00pt "Arial", sans-serif; } .font2 { font:16.00pt "Arial", sans-serif; } .font3 { font:19.00pt "Arial", sans-serif; } .font4 { font:31.50pt "Arial", sans-serif; } Easyflow Ordering key A B C D E F G H Type Size Tube Tube Floater Connection O-ring Fluid code material material material Pos. Description Code Specification A Type: 700 flowmeter type 700 701 flowmeter type 701 750 flowmeter type 750 See page 2/5 751 flowmeter type 751 B Size: DN 10, 15, 20, 25, See page 3 32,...

table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:8.00pt "Arial", sans-serif; } .font2 { font:11.00pt "Arial", sans-serif; } .font3 { font:15.00pt "Arial", sans-serif; } .font4 { font:16.00pt "Arial", sans-serif; } .font5 { font:19.00pt "Arial", sans-serif; } .font6 { font:29.40pt "Arial", sans-serif; } .font7 { font:31.50pt "Arial", sans-serif; } .font8 { font:8.00pt "Microsoft Sans Serif", sans-serif; } Easyflow Accessories Micro Switches The micro switches are clamped on the guide of the flow-meter. A bi-stable reed contact...

table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:8.00pt "Arial", sans-serif; } .font1 { font:11.00pt "Arial", sans-serif; } .font2 { font:16.00pt "Arial", sans-serif; } .font3 { font:19.00pt "Arial", sans-serif; } .font4 { font:31.50pt "Arial", sans-serif; } .font5 { font:6.00pt "Arial Black", sans-serif; } .font6 { font:4.00pt "Trebuchet MS", sans-serif; } Easyflow Technical Data Body material Connection Protection rate Contact resistance Contact insulation resistance Closing time Opening time Working Temperature Contact Material Max operating power Max operating...

table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:11.00pt "Arial", sans-serif; } .font1 { font:13.00pt "Arial", sans-serif; } .font2 { font:17.00pt "Arial", sans-serif; } .font3 { font:31.50pt "Arial", sans-serif; } Further slection of SED product range SED Flow Control GmbH Am Schafbaum 2 D - 74906 Bad Rappenau P.O. Box 1306 D - 74900 Bad Rappenau Phone: +49(0)7264/921-0 Fax: +49(0)7264/921-21 E-Mail: [email protected] Web: www.sed-flowcontrol.com SES an OAliaxis company
