ASO FSO gs Solar- Fuse-Link and Fuseholder www.schurter.com/pg01_2 www.schurter.com/pg02

Non resettable fuses Fuses Midget Fuse, 10.3 x 38 mm, Quick-acting, 1000 VDC, Photovoltaic 1000 VDC · Quick-Acting F Description - UL Recognized for 1000 VDC - Breaking capacity: 20 kA Approvals - UL 248-1 - CSA C22.2 No. 248.1 Applications - String fuse for photovoltaic systems References General Product Information see page XXX Corresponding Fuseholder FSO; 231660 Weblinks Approvals: http://www.schurter.com/approvals RoHS: http://www.schurter.com/rohs CHINA-RoHS: http://www.schurter.com/china_rohs Stock-Check: http://www.schurter.com/stockcheck Accessories: http://www.schurter.com/fuse_accessory...

Non resettable fuses Fuses Touch-Safe Fuseholder, 35 mm DIN-Rail, 10.3 x 38 mm, 1000 VDC 1000 VDC · 600 VAC/DC · 30 A (UL/CSA) Description - Mountable on 35 mm DIN-Rail - Easy installation and removal of fuses - For Fuses up to 100 kA Interrupting Rating Applications - Combiner Boxes in Photovoltaic Systems References General Product Information see page XXX Fuseholder to ASO 10.3x38 Weblinks Approvals: http://www.schurter.com/approvals RoHS: http://www.schurter.com/rohs CHINA-RoHS: http://www.schurter.com/china_rohs Stock-Check: http://www.schurter.com/stockcheck Accessories: http://www.schurter.com/fuse_accessory...

FSO Fuses Variants Holder Remark Order Number l 1 Pole 0091.0001 l 2 Poles 0091.0002 l 3 Poles 0091.0003 Packaging Unit 0091.0001 Bulk (10 pcs.) 0091.0002 Bulk (5 pcs.) 0091.0003 Bulk (4 pcs.) The specifications, descriptions and illustrations indicated in this document are based on current information. All content is subject to modifications and amendments. > ASO the high performance fuse for PV systems together with FSO, a touch safe fuseholder The ASO fuse protects PV modules, conductors and similar DC-applications from the potentially devastating effects of a low short circuit current in...

www.schurter.com/solartech Solar Technology Products Components & Solutions for Renewable Energy Technology > Application Areas Uninterrupted electricity supply represents a key challenge in the 21st century. Photovoltaics (PV) and fuel cells in particular are of special importance because of their sustainability and environmentally friendly energy technology. In contrast to water and wind power, however, these sources produce DC voltage which, in order to be used commercially, must fi rst be transformed into AC voltage at the appropriate line frequency. Tasks Irrespective of the technology used,...

Solution Approaches Various suppliers of frequency inverters have begun specializing in solar inverters. Solar inverters (frequency inverters for PV installations) differ from conventional industrial inverters in that they require only standard designs. Unlike the latter, however, they don’t have to meet individual demands in terms of the physical proximity requirements between the power consumer and the controls. Solar inverters are built using varying components, depending on their power rating. Small, autonomous solar inverters rated at only a few kW have to meet different requirements, in...
