| | | 14 Slot ✓ Area of application: Central Office/Development Laboratory ✓ Optimum utilisation of space when assembled in 19" frames ✓ Cooling up to 200 Watt per board ✓ The system contains: • Chassis with 3 hot-swappable cooling units Including RTM cooling • Redundant power supply DC • Dual Star and Full Mesh backplane •Shelf Alarm Panel (SAP) • Cable management front and rear • Use of two redundant Shelf Managers based on Pigeon Point ShMC 500 possible (bussed or radial IPMI) | | |
| | | 16 Slot ✓ Area of application: Central Office/Development Laboratory ✓ Optimum utilisation of space when assembled in ETSI or 23" frames ✓ Cooling up to 200 Watt per board ✓ The system contains: • Chassis with 3 hot-swappable cooling units Including RTM cooling • Redundant power supply DC • Dual Star and Full Mesh backplane •Shelf Alarm Panel (SAP) • Cable management front and rear • Use of two redundant Shelf Managers based on Pigeon Point ShMC 500 possible (bussed or radial IPMI) | | 5/2 Slot ✓ Area of application: Development Laboratory and Test Systems ✓ For the testing of AdvancedTCA boards, of software and systems design ✓ The system contains: • Chassis with a cooling unit Including RTM cooling • Power supply AC or DC • Full Mesh Backplane • Use of two redundant Shelf Managers based on Pigeon Point ShMC 500 possible (bussed or radial IPMI) | | |
