AdvancedTCA
AdvancedTCA (or short ATCA) stands for Advanced Telecom Computer Architecture. ATCA is the third main group of standards issued by PICMG (PCI Industrial Computer Manufacturers Group) following the passive PCI Backplane and CompactPCI standards.
To read more, please turn to Page 4 - Systems Page 20 - Cabinets
AdvancedMC
t" The AdvancedMC standard Is an Important part of the AdvancedTCA platform.
AdvancedMC modules contain additional boards, which extend the function of a Carrier Board considerably. Parallel to this are the AdvancedMC modules, which are used with the newly defined MIcroTCA systems.
To read more, please turn to Page 24
/jTCA
MIcroTCA Is a very modular standard with the aim, to assemble AdvancedMC modules directly on the backplane without the requirement for a Carrier Board In cost critical applications In the low end area.
To read more, please turn to Page 36
Fast processors create high performance losses and require a carefully thought-out cooling concept - starting from the backplane and up to the cabinet.
To read more, please turn to Page 44
Cooling Concepts
Through further development of AdvancedMC and uTCA additional areas of application have been created. And these are not only usable In telecommunication, but universally:
✓ Communication
• Base stations: WIMAX
✓ Picture processing
✓ Medical technology
✓ Defence technology
✓ Automation
■ --
The AdvancedTCA, AdvancedMC and uTCA standards have been Influenced considerably by Schroff's experts. The focal points of the standards have been summarised for you.
To read more, please turn to Page 46
Standards
3
