| | | | | | | | | | | | | | | | | | | | | | | | | | | AdvancedMC | | | | | | | | | | Guide rails/struts for AdvancedMC module ■ Specific combinations allow to assemble up to 8 AdvancedMC modules (8 x Single Compact) in a Carrier - Strut (splitting extrusion) is assembled between the cover plates (retainer for ESD clip) - Guide rails are clipped into the cover - Board guiding is always done with splitting extrusion (strut) and guide rail | | | | | | | | | | Order Information | | | | | | | | | | | | | | | | | | | Item | Description | Qty/PU | Order no. | | | | 1 | Strut between cover A (left) and B (right), Zn die-cast, nickel-plated | 10 | 20849-009 | | | | 1a | Splitting extrusion (strut) for cover A (left), Zn die-cast, nickel-plated | 10 | 20849-010 | | | | 1b | Splitting extrusion (strut) for cover B (right), Zn die-cast, nickel-plated | 10 | 20849-011 | | | | 2 | AdvancedMC guide rails, PBT, UL 94 V-0, red | 10 | 20849-008 | | | | 3 | ESD clip, spring steel, corrosion-free, for deflection of electrostatics | 50 | 20849-021 | | | | | | | | % | For further information www.schroff.biz/oneclick | | | | oneClick code = Order no. | | | | | | | | | | | | | | | | | | | | | 1 1b 1a 12805071 ESD clip | | | | | | | | | | 12805060 | | | | | | | | | | UK 11/2006 | | | | | | 28 | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
|
