AilmicëtlMC
Differences standard/MF handle for AdvancedMC Carrier
Delivery of Carrier module includes standard front handle
MF handle can be exchanged by a standard handle (if required)
12806063
12805072
■ Insertion/extraction mechanics: 75° opening angle
■ Insertion/extraction in one step
■ Swing range: 23 mm below and above the separation line
■ Included in delivery of Carrier
Insertion/extraction mechanics: 75° opening angle Insertion/extraction in 3 steps (2 operations)
■ Small swing range (0 mm) below and above the pitch line. The lower or upper limit of the Carrier is not exceeded during the extraction.
■ Available on request
UK 11/2006
