AdvancedMO

AdvancedMC Carrier mechanics for Conventional/Cutaway printed boards

■ Carrier mechanics for Industrial mezzanine modules, stainless steel (EMC shielded)

■ 1slot AdvancedMC chassis in accordance with PICMG AdvancedTCA RC 1.1

■ Insertion/extraction mechanics designed for micro switch operation (hot-swap)

■ Height 8 U, width 6 HP, to accommodate up to 8 AdvancedMC modules (Compact)

■ Identical mechanics for Conventional and Cutaway boards Delivery comprises (kit)

12805002

For Conventional printed circuit board/Full-size module


Item	Qty	Description
1		Cover B (on the right), 0.6 mm, stainless steel, insulated interior, exterior with protection film
2		Cover A (left), 0.6 mm, stainless steel, insulated interior, exterior with protection film
3		Splitting extrusion (strut) at bottom, Zn die-cast, nickel-plated
4		Splitting extrusion (strut) at top, Zn die-cast, nickel-plated
5		Front panel at bottom, 1 mm, stainless steel, pressed in alignment pin and retention screws
6		Front panel at top, 1 mm, stainless steel, pressed in alignment pin and retention screws, with holes for LED
7		Standard insertion/extraction mechanics, with micro switch operation, plastic lever, black
8		Standard insertion/extraction mechanics, plastic lever, black
9		EMC profile seal, core: foam, sleeve: textile cladding with CuNi coating
10		EMC profile seal, core: foam, sleeve: textile cladding with CuNi coating
11		Assembly kit
12		Strut A-B (3 pieces), strut for cover A (3 pieces), strut for cover B (3 pieces), ESD clip (8 pieces)
13	10	AdvancedMC guide rail, PBT, UL 94 V-0, red

12805052

For Cutaway printed board/Compact module/Full-size module

Order Information

Description I

AdvancedMC Carrier mechanics for Conventional/

Order no. 1 ... 13 10849-001

Cutaway board with struts, ESD clip, guide rail

AdvancedMC Carrier mechanics for Conventional/

1 ...11 10849-002

Cutaway printed boards Micro switch for AdvancedMC Carrier module (opener) ₂₀₈₄₉ ₀₆₄for soldering (SMD), PU 10 pieces ^20849-064

Micro switch for AdvancedMC Carrier module (closer)

for soldering (SMD), PU 10 pieces

20849-020

Note

■ Hybrid Carrier, see page 29

■ Carrier for Mid-size AdvancedMC modules, see page 30

■ Please order strut (item 12), ESD clip and guide rails (item 13) separately, see page 28

■ AdvancedMC module mechanics, see page 32

■ Description micro switch, see page 35

12805053

UK 11/2006
