AûvanceûTCA
VARISTAR LHX 20 for Advanced TCA
■ Cabinet IP 55, RAL 7021 with air/water heat exchanger
■ Assembly dimensions coordinated for the assembly of AdvancedTCA subracks (cabinet depth 800 mm)
■ Air/water heat exchanger 20 kW alternatively for voltage supply with 48 Vdc or 230 Vac, assembled on the left (right side possible too)
■ Max. static load-carrying of the 19" plane: 800 kg
Delivery comprises (completely assembled and GND/earthed)
Qty
1
1 1
Item
1
2 3
Description
Welded basic frame, St profile, RAL 7021, zinc-plated
with all-round industrial seal IP 55
Flat top cover, St, RAL 7021
Front door, glazed, RAL 7021, safety glass 6 mm,
180° hinge, 4 point locking, lever handle for optional
DIN profile half cylinder
Rear door, St, RAL 7021, 180° hinge, 4 point locking, lever handle for optional DIN profile half cylinder Side panel screw-fixed, St, RAL 7021 Base plate, St, RAL 7021, cable entry at rear, entry for water connection at front, connections can be sealed with sliding panels
Base/plinth 100 mm, St, RAL 7021, removable covers, adjustable feet integrated
19" panel/slide mount with EIA cut-outs, St, RAL 7021, 175 mm recessed at front, distance 500 mm between front and rear 19" plane
Support rail for the assembly of the air/water heat exchanger and 19" panel/slide mounts, St, RAL 7021 Air baffle, for optimal airflow, St, RAL 7021 Air/water heat exchanger, 20 kW, RAL 7021, assembled on the left User Manual
4
7
8
4
9
2
10
11 12
Order Information
Height
Height H
Width W
Depth D
Description
Order no.
U
mm
mm
mm
42
2100
800
800
230 Vac
10130-010
42
2100
800
800
48 Vdc
10130-011
DIN semi-profile cylinder, common locking (1 key fits into all locks) incl. 2 keys Lifting eye PU 4 pieces
25127-995 23130-072
■ Technical data air/water heat exchanger, see page 23
For further information www.schroff.biz/oneclick
oneClick code = Order no.
01005091
UK 11/2006
22
