AdvancedTfifl
SERVICE ...
... the number one priority at Schroff
From the start our application engineers will be at your side worldwide. Components which are available ex stock provide short delivery times, which save time and money. In the after sales area too we offer extensive support. Our friendly, worldwide team of experts Is at your disposal at all times.
Cooling capacity
up to 20 kW
er cabinet
Operating principle of the air/water heat exchanger manufacturer
Electronic Monitoring Unit with Display and Interfaces
VARISTAR LHX 20 -advantages at a glance
✓ Even cooling of all systems over the entire assembly height
✓ The entire heat loss Is expelled via the cool water circulation
✓ Optimum system adjustment and safety through:
• preventative control and regulation
• Integrated alarm and communication Interfaces
✓ Noise level smaller than 55dB(A), even suitable for office environments
Safety and Monitoring
During the development of the LHX 20 particular importance was placed on safety and the monitoring functions:
✓ System monitoring through AdvancedTCA Shelf Management
✓ Interface RS 232 for external cabinet monitoring
✓ Redundant 48VDC supply
✓ Condensation is controlled with an Integrated droplet collector that avoids water In the air expulsion area
✓ The water and power supply is arranged from the bottom
21
