AävancedTCA

AdvancedTCA filler panel

■ Front panels from stainless steel or Al extrusion

■ 6 HP filler panel in 3 versions

- Front: Filler panel with air baffle (item 1, air baffle blocks the air from unused slots)

- Rear: Filler panel with air baffle (item 2, air baffle blocks the air from unused slots

- Only filler panel (item 3)

Delivery comprises (kit)


Item	Qty	Description
1	1	Filler panel
2	1	Separating panel (front or rear)
Order Information
Item	Height Width		Depth W		Description	Order no.
	U	HP	mm	mm
					Filler panel Al
1	8	6	280	30.14	extrusion, incl. air baffle with mesh industrial seal	21596-008
					Filler panel stainless
1	8	6	280	28.95	steel, incl. air baffle with mesh seal	21591-079
					Filler panel Al
2	8	6	70	30.14	extrusion for rear I/O area incl. air baffle with mesh seal	21591-107
					Filler panel stainless
2	8	6	70	28.95	steel for rear I/O area incl. air baffle with mesh seal	21591-099
					Filler panel Al
3	8	6	—	30.14	extrusion with mesh seal	21591-104
3	8	6	-	28.95	Filler panel stainless steel with mesh seal	21591-097
Note
■ Version with CuBe seal available on request
4	For further information www.schroff.biz/oneclick
4	oneClick code = Order no.

12705062

Item 1

Item 2

Item 3

12705064 12705061 12705063

UK 11/2006
