Info_SPS_55_2010.indd table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:36.00pt "Arial", sans-serif; } .font1 { font:4.00pt "Microsoft Sans Serif", sans-serif; } .font2 { font:5.00pt "Microsoft Sans Serif", sans-serif; } .font3 { font:6.00pt "Microsoft Sans Serif", sans-serif; } .font4 { font:8.00pt "Microsoft Sans Serif", sans-serif; } .font5 { font:28.00pt "Microsoft Sans Serif", sans-serif; } Features: • Automatically focuses on z-height utilizing topographic lens data transmitted via data interface from suitable server systems (e.g. Satisloh's RX-Server-AF) • Highest consistency of engraving quality and visibility among available CO2 laser-based engravers • Integrates with Satisloh's free-form solu­tion, communicates with RX-Server-AF - LensMark RX via TCP/IP • Open data communication interface • Protocols: VCA (OMA) via RS232 or ethernet LDCS using Satisloh LensMark RX soft­ware • Optimized process through material specific engraving parameters • Job numbers readable from paper tickets, bar-coded trays or RFID • CO2 laser engraver especially for semi-vis­ible and visible markings on free-form/pro-gressive lenses • Engraves micro circles, characters, logos (dxf or dwg) and geometric shapes on all organic lens materials, convex and concave • Engraved lenses can be hard-, AR coated and tinted • Accepts Satisloh blocking chucks • Power adjustment kit maintains quality and visibility of engravings • Availability: - stand-alone version (manual) - desk-top version (manual) - automatic version (automated loading/ unloading) Operation screen of laser Benefits: • Low operating costs and costs per lens since virtually consumable free processing and minimal maintenance needed • Short process time • Manual system upgradable to automated loading/unloading system • High quality, reproducible results • High reliability and yield • Small foot print • Continuous operation, long lifetime laser source • Safe system, secure operation - requires no protective eyewear for operator • Sealed CO2 laser source, requires no gas installation • User friendly software for operation, cali-bration, control and graphical layout design • Fixed or variable engraving objects Technical Information: Materials: all organic lens material like CR39, high index material, Trivex and polycarbonate Working Range: convex and concave engravings anywhere on the lens up to 80 mm diameter Lens Reception: Satisloh blocking chucks Included: PC based on a Microsoft Windows™ operating system Laser: sealed off CO2 laser class I Wave Length: 10200 - 10800 nm Electric Energy Requirements: 230 V/6 A or 110 V/12 A, 50/60 Hz air cooling (exhaust required) Dimensions and Weight (w x d x h): Desk-top 515 x 1340 x 827 mm / 20 x 52 x 32 inches 210 kg / 463 lbs Stand-alone 1056 x 1347 x 1322 mm / 41 x 53 x 52 inches 316 kg / 697 lbs Automated 1188 x 1661 x 1387 mm / 46 x 65 x 54 inches 400 kg / 882 lbs e c -­a * n 2 CCI o s 0 Contact Satisloh AG Sales Service Neuhofstrasse 12 North America Phone: +1 262 255 6001 +1 262 255 6001 CH - 6340 Baar Email: info.usa@satisloh.com service.usa@satisloh.com Switzerland Phone: +41 (0) 41766 16 16 Europe Phone: +49 (0) 6441 912 0 +49 (0) 6441 912 222 Fax: +41 (0) 41766 16 10 Email: info.de@satisloh.com service.de@satisloh.com Mail: info@satisloh.com Asia Phone: +852 27 56 7711 +852 27 56 7654 www.satisloh.com Email: info.asia@satisloh.com service.asia@satisloh.com satisloh
