Type code combination of F series driver + H series motor

4-< 3

a _in

Set part number

Motor model number

System type

Motor flange size Basic step angle

Rated current

Standard model

u O

Specifications of driver

■ F series driver

Item

PMDSA1S3P01

0 to +50 C

Operating ambient temperature


	Conservation temperature	-20 to +70"C
	Operating ambient humidity	35 to 85% RH (no condensation)
	Conservation humidity	10 to 90% RH (no condensation)
	Vibration resistance	0.5G Tested under the following conditions, frequency range : 10 to 55Hz, direction : along the X, Y, and
	Vibration resistance	Z axes, for 2 hours
	Impact resistance	1 Considering the NDS-C-0110 standard section 3.2.2 division "C" , not influenced
	Withstand voltage	Not influenced when AC500V is applied between power input terminal and cabinet for one minute
	Insulation resistance	10M 0 when measured with DC500V megohmmeter between

Basic

specifications

Environment

Mass (Weight)

0.14kg (0.31lbs)

UL Standards

UL508C

Applied Standards

File No.

E179775

(A 3

Auto current down, step angle, pulse input method (optional)

Selection function

Functions

Photo coupler input method, input resistance 330 0 Input signal voltage : H = 4.0 to 5.5V

L = 0 to 0.5V Maximum input frequency : 50kpulse/s

Command pulse input signal

I/O

signals

Photo coupler input method, input resistance 330 0 Input signal voltage : H = 4.0 to 5.5V L = 0 to 0.5V

Power down input signal

Open collector output by photo coupler

Output signal standard, Vceo = 30V MAX., Ic = 5mA MAX.

Rotation monitor output signal
