SANDEX

Option

Miniature motor mounting specifications

198

MQX262

135

67.5

-€3-

C-B MOTOR/

«165

105

V TIMING PULLEY-A

227

The * Indicates the dimensions without a clutch/brake unit.

To find the value for D.refer to the timing transmission specifications.

Figure 01FM-3

285

Timing transmission specifications

Induction motor specifications

Table 01FM-2

Table 01FM-4


Timing pulley reduction	Pulley Â Hutuber af teeth	Pulley B HttœÈer	D	Belt Number
1	21	21	138	187L 50 teeth
1.14	21	24	131	187L 50 teeth
1.24	21	26	126	187L 50 teeth
1.33	21	28	150	210L 56 teeth
1.43	21	30	145	210L 56 teeth

Type

Motor model

Output

power (W)

№)

Voltage (V)

Current (A)

Starting torque

»gf-m>

Rated torque

(kgf-m:

SotattBg speed

(rpiii)

G>F)

Gear head model

Ballbearing type

tateraiedìate gear head

No clutch and brake

51K40GN-A

50 60

100

0.8

0.02

0.03 0.026

1300 1550

10.0

5GNQK

5GN10XK

With clutch and brake

CBI540-701

5GCOK

Allowable torque with gear head Table 01 fm-3


Rotating speed	200	120	100	SO	SO	30	20	IS	10
50Hz Gear ratio	7.5	12.5	15	25	30	50	75	100	150
60Hz Gear ratio	9	15	18	30	36	60	90	120	180
Allowable torque(kgf«m)	0.18	0.3	0.36	0.55	0.66	1.0	1.0	1.0	1.0

Clutch and brake Eificatlons

Table 01 FM-5


	*"^^--^^^ Motor Stout •••,^^~—>~-^.*	40W
	*"^^--^^^ Motor Stout •••,^^~—>~-^.*	Clutch j Brake
	Static frictional torque	0.15kgf.m
	Dynamic frictional torque	O.lkgf.m
	Rated voltage	DC24V
	Power consumption(at 75°C)	7W \| 5W
	Armature pull - in time	15msec
	Armature release time	25msec
	Actual torque build - up time	20msec
	Repetition rate	max. 100 times / min
	Total energy	1.5xl0⁶kgfm
	Allowable energy at one time	0.15kgfm

Special notes

•The figures in the q indicate gear ratio.
