Table FN-3

Table of FN Series Dimensions

(Unit: mm)

I & U -dimensions changes with reducer sizes Table FN-4

Table of FN Series Specifications


Property	Symbol	Unit	12FN	16FN	22FN
Output allowable carrying load	W0	N	Please contact Sankyo
Output allowable axial load	P1	N	280	490	705
Output allowable radial load	P2	N	200	274	392
Output torsional rigidity	K1	N m/rad	1.65 x 10⁴	2.05 x 10⁴	3.33 x 10⁴
Input allowable axial load	P3	N	1470	1470	2940
Input allowable radial load	?	N	2300	2352	6860
Input max. repetitious allowable	P5	N m	220	225	921
torque
Input torsional rigidity	K2	N m/rad	1.66 x 10⁴	2.05 x 10⁴	9.80 x 10⁴
Approx. Oscillating accuracy		arc min	±10	±10	±10
Approx. Repetitive accuracy		arc sec	60	60	60
Approx. Lifting accuracy		mm	±0.1	±0.1	±0.1
Product weight		kg	70	110	240

*Specifications and dimensions are subject to change without notice. Always double check before ordering.

[B (in.-lbs.) / A (N m) x 8.851]
