Model Selection information

Sandex model codes are specified by a combination of numbers and alphabetic characters. An erroneously specified product code will usually result in a product unusable in other applications. Use the same caution when specifying the product code for the geared motor and optional torque limiters. When specifying other requirements such as special gear ratios, motor voltages, copper plated terminal boxes, etc., include the symbol X at the end of the product code and attach a separate user requirements sheet. Queries concerning price, volume, and delivery should be directed to a Sankyo salesman or representative.

Output

Mounting Holes

Mounting Position

Special Instruction

Input Shaft Projection

Standard

Both T and U surface

Input shaft projection as shown below.

7AD--23AD

1, 2, R1 become special order 33AD & 45AD

In case of input shaft project­ing at the both side, one side will be extended shaft for installation timing cam.

Include the symbol IXi in case of special orders

I I Standard

(No Symbols)

Xj Special Instructions

7AD--23AD

Tapped mounting holes on surface V and through mounting holes on surface W come automatically.

33AD & 45AD

Tapped mounting holes on

surface R,V,W come

automatically.

Standard

with Torque Limiter on output

Mounting position as shown below.

■ I are available

|T1 (Special order)

S

V

T

U

T

GL(R)

SE

(Special order)

S

GL(V)

R

Model code example

4
