Specifications of geared motor

Table 45AD-2


Code	Motor Power (kW)	Actual Gear Ratio	Output Shaft Speed NM(rpm)		Output Allowable Torque TR(N-m)		Moment of inertia jM(kg-m²)	Weight (kg)
230V	Motor Power (kW)	( i )	50Hz	60Hz	50Hz	60Hz	Moment of inertia jM(kg-m²)	Weight (kg)
GM11-19.23BS-45AD		19.23	75	90	1320	1110
GM11-23.59BS-45AD		23.59	61	73	1610	1350
GM11^-26.39BS^-45AD		26.39	55	66	1800	1510
GM11^-32.60BS^-45AD	11	32.60	44	53	2160	1820	40.0X10^-3	245
GM11^-36.05BS^-45AD	11	36.05	40	48	2380	2000	40.0X10^-3	245
GM11^-40.65BS^-45AD		40.65	36	43	2680	2250
GM11^-44.89BS^-45AD		44.89	32	39	2950	2480
GM11^-49.87BS^-45AD		49.87	29	35	3270	2750
GM15^-9.55BS^-45AD		9.55	153	183	890	745
GM15^-15.42BS^-45AD		15.42	95	114	1430	1200
GM15^-21.23BS^-45AD		21.23	69	82	1970	1640
GM15^-26.39BS^-45AD	15	26.39	55	66	2430	2040	92.5X10^-3	310
GM15^-32.60BS^-45AD	15	32.60	45	54	2920	2450	92.5X10^-3	310
GM15^-36.05BS^-45AD		36.05	41	49	3230	2700
GM15^-40.65BS^-45AD		40.65	36	43	3630	3040
GM15^-44.89BS^-45AD		44.89	33	39	4000	3350

Torque limiter mounting specifications(option) Fig_ure 45AD-3

2-M4


switch

Extension shaft

Sensor Model EE-SX672(OMRON) Connector Model EE-1001

Example Model Code

Timing Cam-Photo Switch | TC | - |T~1 - 45AD

Mounting extended shaft

Precautions

•The dimension drawing(Figure 45AD-1, 45AD-2) shows the standard mounting position for geared motor. •Model 45AD can be equipped with 11kW and 15kW motor. 18.5kW motor is also available as special instructions. •Up to 3 sets of timing cams and photo swiches can be added as necessary. •The timing cam can be freely adjusted to any period( a )below 180°.

Standard input shaft(T surface side) /

Locations of oil plug, etc., and oil capacity

Figure 45AD-6

Mounting position

2 5

Location

345

395

400

Figure 45AD-4

Oil capacity(ê)

Output fixed flange specifications

115

105

115

Precautions

•Each point indicated in the mounting positions shown in Figure 45AD-6 represents (starting at top) the oil plug (PT1) , oil level (VB) , and drain (PT1) .

•The mounting positions correspond to code i for the indexing drives.

•The oil capacities indicated in Figure 45AD-6 are given in general figures and will differ according to the profile of the cam and the number of cam followers.


	/
		m

Through W surface)

Output shaft

Figure 45AD-5
