SAFTTY ELECTRONIC TECHNOLOGY SAFTTY •Y] overheat under control J KEY BENEFITS £iïfë§& © Miniature size @ Positive make and break with snap-action dise © Compétitive price © Suitable for most imprégnation processes APPLICATION JSffilSB © HID ballasts © DC motor © Battery packs © Heating appliance © Fractional Power Motor © Transformer © Ac brushless motor and pump CERTIFICATIONS WM V r i ,/ / / SAFTTÏ " " Kt --» c | |-H-(_I-1 3 - 16 (-%-1 1-1 LEADWIRE 40^-120^--3266,AWG 22#, 125t; -145t:-- 3398 AWG22# or Nickel strip normally.length is 60mm or according to customer' s require. AGENCY STANDARD NUMBER APPLICATION VDE EN60730-2-2 Motor protection UL UL2111 Motor protection MAXIMUM CONTACT RATINGS VOLTAGE CURRENT CYCLES 250V 6A 10000 24V 6A 10000 CODE SYSTEM BW-XXX-XXt > Open Température WifÈ/mfi > M-metai close P-plasticcase HîS > C-normally close gf|ï, O-normally open ^fffllï > D-small size /JvSfll > Device No. îtqnMS OPEN TEMP & RESET TEMP BW-DCP-95°C 95+5°C 70 + 15°C BW-DCP-10CTC 100+5°C 75 + 15°C BW-DCP-105*C 105+5°C 80 + 15'C BW-DCP-110°C 110+5°C 85+15*C BW-DCP-115"C 115+5°C 90+15°C BW-DCP-120°C 120±5°C 95+15eC BW-DCP-125°C 125±5°C 100 + 15°C BW-DCP-13CTC 130+5°C 105±15*C BW-DCP-135°C 135+5°C 105±15°C BW-DCP-14CTC 140+5°C 110 + 15°C BW-DCP-145°C 145 + 5°C 115 + 15°C lnDgSf BW-DCP-40°C 40±5°C ^27°C BW-DCP^5°C 45±5°C >30°C BW-DCP-50°C 50±5'C >33°C BW-DCP-55°C 55±5*C 43+10°C BW-DCP-60°C 60±5°C 45+10°C BW-DCP-65°C 65±5°C 48+12eC BW-DCP-70°C 70±5°C 50±12°C BW-DCP-75°C 75±5°C 53±15°C BW-DCP-80°C 80±5°C 55+15°C BW-DCP-85°C 85+5°C 60+15°C BW-DCP-90°C 90±58C 65±15°C Company add:2nd floor NO.4 building.Qinghuafang.Xingye road.Panyu, Guangzhou.China Tel:86 20-34826856 Fax:86 20-62351066 Ext.802 E-mail:webmaster@thermtector.com Website:www.thermalprotector.cn www.saftty.com %iS:86 20-34826856 ff K:86 20-62351066 ext:802 fiISfë: webmaster@thermtector.com mit; www.thermalprotector.cn www.saftty.com
