| | | FLEXBEAM-3™ AND FLEXBEAM-2™ COUF metric dimension series • stainless steel | | |
| | | MWC/MWS | | |
| | | |
| | | |
| | | PART NUMBER SPECIFICATIONS PERFORMANCE | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | CLAMP STYLE | SET SCREW STYLE | BORE OUTER SIZE DIAM (mm) OD (mm) | LENGTH LENGTH L (mm) L (mm) (MFC/MWC) (MFS/MWS) | CLEARANCE CAP SET DIAM C (mm) SCREW SCREW MAX (MFC) (MFC/MWC) (MFS/MWS) | STATIC TORQUE (Nm) | WIND-UP (Deg/Nm) | PARALLEL MISALIGNMENT (mm) | AXIAL MOTION (mm) | MOMENT OF INERTIA (x10-6 kg-m2) | | | | MFC20 | MFS20 | 5 6 8 | 20 | 30 | 30 | 22.8 M3 | M4 | 4.60 4.60 3.60 | 0.69 0.69 0.70 | 0.20 | 0.12 | 3.306 | | | | | | 6 | | | | | | 6.10 | 0.29 | | | | | | | MFC25 | MFS25 | 8 10 12 | 25 | 40 | 40 | 30.2 M4 | M5 | 5.60 5.60 3.90 | 0.42 0.42 0.86 | 0.38 | 0.25 | 11.060 | | | | | | 8 | | | | | | 15.50 | 0.20 | | | | | | | MFC30 | MFS30 | 10 12 14 | 30 | 45 | 45 | 34.9 M5 | M6 | 15.50 13.50 10.90 | 0.20 0.26 0.44 | 0.38 | 0.25 | 25.455 | | | | | | 10 | | | | | | 23.56 | 0.17 | | | | | | | MFC40 | MFS40 | 12 14 16 | 40 | 55 | 55 | 45.6 M6 | M6 | 23.56 23.00 23.00 | 0.17 0.27 0.27 | 0.76 | 0.38 | 97.667 | | | | MWC15 | MWS15 | 3 4 5 | 15 | 22 | 20 | M2 | M3 | 1.30 1.30 1.20 | 2.23 2.23 2.52 | 0.20 | 0.12 | 0.731 | | | | MWC20 | MWS20 | 4 5 6 | 20 | 28 | 20 | M3 | M3 | 2.00 2.00 1.70 | 0.98 0.98 1.29 | 0.20 | 0.12 | 2.984 | | | | MWC25 | MWS25 | 6 8 10 | 25 | 30 | 24 | M3 | M4 | 5.10 5.10 4.60 | 0.58 0.58 0.83 | 0.38 | 0.25 | 7.871 | | | | MWC30 | MWS30 | 8 10 12 | 30 | 38 | 30 | M4 | M5 | 10.40 10.40 10.00 | 0.33 0.33 0.46 | 0.38 | 0.25 | 20.920 | | | | | | | | | | | | | | | | | | | | |
| | | |
| | | Note 1 Static torque ratings are at maximum misalignment. To obtain dynamic rating, static ratings should be divided by 2 for non-reversing applications and by 4 for reversing applications. Note 2 Hardware is alloy steel with black oxide finish. Stainless steel hardware is available upon request. MFC and MWC series parts have two socket head Nypatch® cap screws on each end. MFS and MWS parts have two set screws on each end 120° apart. Note 3 Performance ratings are for guidance only. The user must determine suitability for a particular application. Note 4 Coupling torque and wind-up are determined by the largest bore selected. Note 5 Angular misalignment on all couplings is 3°. Note 6 Shafts may penetrate up to 0.5 x L. Be certain shafts do not touch. | | |
| | | |
| | | :or engineering and warranty/disclaimer information, see p. 3 or www.ruland.com | | |
| | | |
