RTKIntrinsically Safe Multiplexers

Multiplexers - 19514 S10/SA S10/HA 2

Switch Receiver Switch Transmitter

The S10/SA receiver unit gives relay changeover contacts and LED drive outputs foreach of the ten input circuits connected to the hazardous area transmitter. The system includes effective fault monitoring in which the normally energised monitor outputs are de-energised on data corruption. Introduced as the worlds first intrinsically safe switch multiplexer, the popularity of the simple and compact S10 system remains undiminished. The S10/HA transmitter accepts signals from switch contacts, and transmits their status to the safe area receiver on a single cable pair, which also carries the power requirements of the transmitter. A particular feature is the very fast response time to changes in input status.

Technical Data Technical Data

Supply voltageVs nom volts 24 d.c. Supply:barrier S936, S937 limits 22-30 or isolator E1520 current 250 mA max., all LED options in use, or 150 mA max. LED options not used. No. of channels 10 Response time 6.4mS max. No. of channels 10 Field inputs, type Contacts Contact outputs One c/o contact set per channel, volt- wetting current 50 µ A free, energised while the field contact is open. Phase Selectable contacts open, or closed for outputs ‘on’. Ratings 1A at 110V a.c. or 30V d.c. resistive. Reactive loads must be suppressed. Temperatureoperating -10 to +55
o C storage -30 to +70
o C Life 10
8 operations minimum. Operating range Up to 2km approx. LED outputs One per channel, 12V via 1K, 10mA per LED, energised while the field contact Terminals Series BLZ, detachable,.with retainers is open. Construction Blue resin encapsulated block, for Fault detection Fault outputs de-energise in presence surface mounting. of fault or data corruption. Dimensions 171mm by 84mm by 16mm high Fault outputs LED drive and volt-free c/o contact set. excluding connectors. Channel outputs remain in their last state. Weight 515 grams, with connectors. Temperatureoperating -10 to +50
o C. Vs should be limited to Fixings By four holes M3 clear on 152 x 52mm 25V max. in ambient temperatures centres. exceeding 30
o C. Location Hazardous area. storage -30 to +70
o C Terminals Qty. 8, Weidmuller BL8, detachable. CertificationEurope Category EExia IIC T5 (Ta - 55
o C), BASEEFA Certificate No. Ex822237/3 Construction White steel enclosure, for surface System Certificate No. Ex98D2064 mounting. Dimensions 195mm by 105mm by 18mm high Safety ParametersU
i volts BASEEFA 30FM 32 excluding connectors. I
i milliamps BASEEFA 660FM 350 P
i watts BASEEFA 1.3- Weight 650 grams, with connectors Fixings By four holes M3 clear on 172 x 61mm centres. Location Safe area. EMC Compliance: EMC Compliance: Industrial Environment Emission - BS EN 50 081-2 Industrial Environment Emission - BS EN 50 081-2 Immunity - BS EN 50 082-2 Immunity - BS EN 50 082-2

Ordering Data Cat. No. Ordering Data Cat. No.

S10/SA S10/HA2
