DF40 Version DFR30IS Version The same display type and features but
based on a 40mm grid structure giving
window sizes of 40 x 40mm, 80 x
40mm and 80 x 80mm. This unit is an Intrinsically Safe backlit
display which can be mounted in any
Zone 1 or Zone 2 hazardous area. See
separate datasheet for full details. DF30LC Version
DF30 Specials
DFR30 Version This is a lower cost LED illuminated
display that can be connected directly to
48 or 110VDC. The rear terminal board
includes an efficient DC/DC converter to
drive the LEDs from the higher voltage.
Available in blocks of 4 wide by 2 high
small windows. This is the same as the DF30 Display
but has the wider, larger frame to match
the 725 Series Annunciator. Overall and
cut-out dimensions are the same as the
P725LO product. In addition to the standard DF30 Display
Facia there are a number of specials
that are supplied to suit particular
applications, these include the following:
IP65 Displays
Display Details The IP65 displays are custom built
using backlit
LED display windows of
two different sizes, either 24 x 18mm or
36 x 24mm. Both are backlit by
multichip LEDs to maintain the security
and provide a maintenance free display.Arrays of almost any shape and sizecan be manufactured to suit the exactdisplay requirements.
The LEDs are available in red, amberand green. These can be combined with
IP65 sealed, matching pushbuttons to
provide the standard controls for Lamp
Test, Accept and Reset.All the display modules are pre-wired toa row of terminals making connection a
simple task. The units are also supplied
with a matching gasket to provide the
seal to the mounting surface.
Due to our policy of continuous product development, we reserve the right to amend specifications without notice.
