Do you need a rotating union that isn’t in any catalog? One that can handle 20,000 PSI? One that runs at 20,000 RPM? One that works at 2,000°F? You’ve come to the right place. Rotary Systems specializes in custom-designed and custom-built rotary unions that meet the exacting requirements of our customers. We make products designed for a wide variety of applications. The process of building your rotating union starts with our experienced engineering team working with your requirements and the latest CAD/CAM technology, including AutoCad® and TEKsoft.® The manufacturing itself is done with...

I N D E X R E Q U I R E M E N T S STANDARD & OPTIONAL MATERIALS Standard Materials Hydraulic Service: Shaft — 12L14 steel, case hardened to 60 Rc. .040 deep, plated with black oxide Housing — 12L14 steel, plated with black oxide Standard Materials Water Service: Shaft — 12L14 steel, plated with Melonite® Housing — 12L14 steel, plated with Melonite® Pricing: Based on quantity breaks of 1, 10, 25, 50, 100 Warranty: All standard parts have 1-year unlimited warranty Optional Materials: 303, 304, 316, 420 stainless steels, brass, aluminum, tool steels, plastics, exotics Also available: hard...

R O T A R Y S Y S T E M S I N C 1 • 8 0 0 • 9 5 9 • 0 1 4 6 w w w. r o t a r y s y s t e m s . c o m DESCRIPTION SPEED VS PRESSURE OPERATING SPECS 0 0 1 S E R I E S R O T A T I N G U N I O N S 250 125 0 500 0 1000 3000 5000 1/2" NPT 1/4" NPT RPM PSI Rotary Systems’ entry-level 90° swivel is designed for the hose reel industry. This economical swivel uses a hardened and ground shaft, and impregnated Teflon seals. The 001 series is able to withstand high pressures, moderate speeds, and low side loads. PART # A THREAD B LENGTH C DIAMETER D HEX 10010 0.125 NPT 1.480 1.250 0.500 11010 0.250 NPT...

R O T A R Y S Y S T E M S I N C 1 • 8 0 0 • 9 5 9 • 0 1 4 6 w w w. r o t a r y s y s t e m s . c o m DESCRIPTION SPEED VS PRESSURE OPERATING SPECS 0 0 2 S E R I E S R O T A T I N G U N I O N S Rotary Systems’ 90° swivel is designed for the car wash industry. This economical swivel uses a hardened and ground shaft, impregnated Teflon seals, and Oilite® bronze bearings. The 002 series is able to withstand high pressures, moderate speeds, and moderate side loads. 500 750 250 0 500 0 1000 3000 5000 1" NPT 1/2" NPT 1 1/2" NPT RPM PSI • Maximum Hydraulic: 7000 PSI • Maximum Air: 500 PSI • Maximum...

R O T A R Y S Y S T E M S I N C 1 • 8 0 0 • 9 5 9 • 0 1 4 6 w w w. r o t a r y s y s t e m s . c o m DESCRIPTION SPEED VS PRESSURE OPERATING SPECS 0 0 3 S E R I E S R O T A T I N G U N I O N S 6 Rotary Systems’ 90° swivel is designed for heavy-duty use. This economical swivel uses a hardened and ground shaft, impregnated Teflon seals, and deep-groove ball bearings. The 003 series is able to withstand high pressures, moderate speeds, and high side loads. 1500 1000 500 0 500 0 1000 3000 5000 1" NPT 1/2" NPT 1 1/2" NPT RPM PSI • Maximum Hydraulic: 7000 PSI • Maximum Air: 500 PSI • Maximum...

R O T A R Y S Y S T E M S I N C 1 • 8 0 0 • 9 5 9 • 0 1 4 6 w w w. r o t a r y s y s t e m s . c o m DESCRIPTION SPEED VS PRESSURE OPERATING SPECS 0 0 4 S E R I E S R O T A T I N G U N I O N S 7 Rotary Systems’ 90° swivel is designed for super-heavy-duty use. This swivel uses a hardened and ground shaft, impregnated Teflon lip seals, and deep-groove ball bearings. The 004 series is able to withstand very high pressures, moderate speeds, and high side loads. 2500 1875 1250 625 0 1000 0 3000 5000 7000 1/2" NPT 1 1/2" NPT RPM PSI B A THREADa C D HEXa PART # A THREAD B LENGTH C DIAMETER D HEX...

R O T A R Y S Y S T E M S I N C 1 • 8 0 0 • 9 5 9 • 0 1 4 6 w w w. r o t a r y s y s t e m s . c o m DESCRIPTION SPEED VS PRESSURE OPERATING SPECS 0 0 5 S E R I E S R O T A T I N G U N I O N S 8 Rotary Systems’ entry-level inline swivel is designed for light use. This economical swivel uses a hardened and ground shaft, and impregnated Teflon seals. The 005 series is able to withstand moderate pressures, low speeds, and low side loads. 150 75 0 250 0 500 750 1000 1/2" NPT 1/4" NPT RPM PSI • Maximum Hydraulic: 1500 PSI • Maximum Air: 250 PSI • Maximum Vacuum: 28 Hg • Maximum Temperature: 400°...

R O T A R Y S Y S T E M S I N C 1 • 8 0 0 • 9 5 9 • 0 1 4 6 w w w. r o t a r y s y s t e m s . c o m DESCRIPTION SPEED VS PRESSURE OPERATING SPECS 0 0 6 S E R I E S R O T A T I N G U N I O N S 9 Rotary Systems’ inline swivel is designed for multipurpose use. This economical swivel uses a hardened and ground shaft, impregnated Teflon seals, and Oilite® bronze bearings. The 006 series is able to withstand high pressures, moderate speeds, and moderate side loads. B A THREADa C PART # A THREAD B LENGTH C DIAMETER 10111 0.125 NPT 1.870 1.000 11111 0.250 NPT 2.390 1.500 12111 0.375 NPT 2.540...

R O T A R Y S Y S T E M S I N C 1 • 8 0 0 • 9 5 9 • 0 1 4 6 w w w. r o t a r y s y s t e m s . c o m DESCRIPTION SPEED VS PRESSURE OPERATING SPECS 0 0 7 S E R I E S R O T A T I N G U N I O N S 10 Rotary Systems’ inline swivel is designed for heavy-duty use. This swivel uses a hardened and ground shaft, impregnated Teflon seals, and dual ball bearings. The 007 series is able to withstand high pressures, moderate speeds, and high side loads. 1500 1000 500 0 500 0 1000 1500 2500 1" NPT 1/2" NPT 1 1/2" NPT RPM PSI • Maximum Hydraulic: 3000 PSI • Maximum Air: 500 PSI • Maximum Vacuum: 28 Hg •...

R O T A R Y S Y S T E M S I N C 1 • 8 0 0 • 9 5 9 • 0 1 4 6 w w w. r o t a r y s y s t e m s . c o m DESCRIPTION SPEED VS PRESSURE OPERATING SPECS 0 0 8 S E R I E S R O T A T I N G U N I O N S 11 • Maximum Static Pressure: 350 PSI • Maximum Air Pressure: 250 PSI • Maximum Vacuum: 28 Hg • Maximum Temperature: 400° F • Maximum speed up to 15,000 RPM Rotary Systems’ inline swivel is designed for high speeds. This swivel uses a hardened and ground shaft, mechanical seal, and dual ball bearings. The 008 series is able to withstand low pressures, high speeds, and high side loads. 3600 1800 0 150...
