GASKETING

• Excellent oil and chemical resistance• One product for any size, type or shape of gasket • Resists high pressure when fully cured

X15-18 FAST GASKET

PartCode Unit Size

Fast curing flexible liquid gasket to replace pre-cut gaskets. Designed for rigid metal flangefaces especially aluminium. Instant seal and fills gaps up to 0.5mm. Excellent oil and chemical resistance. Ideal for sealing motors, transmission assemblies and gearboxes. Maximum Gap Filling (mm): 0.50mm. Adhesive Strength (N mm 731937319650ml300ml
2 ): 7 - 10 N/mm
2 .Temperature Range: –55 to +150 ºC.

X15-74 MULTI GASKET

PartCode Unit Size

General purpose flange sealant. Designed to replace pre-cut gaskets. Seals on damaged flange faces and fills gaps up to 0.5mm. Very fast curing product even at low temperatures. Ideal for sealing, drive axles, gearbox and pump housings. Maximum Gap Filling (mm): 0.50mm. Adhesive Strength (N mm 73203 7320650ml300ml
2 ): 17 - 22 N/mm
2 . Temperature Range: –55 to +150 ºC.

THREADSEALING

• Instant low pressure seal for all types of pipe connections• Fittings can be easily dismantled with normal hand tools • Replaces PTFE tape, hemp and pastes • Excess product will not cause a blockage – easily flushed away

X15-42 HYDRAULIC SEAL

PartCode Unit Size

Use on fine threaded fittings up to 20mm diameter. For both hydraulic and pneumaticsystems. Locks and seals providing structural integrity. Vibration Resistant. Diameter-Maximum Gap (mm): 20mm Dia. - 0.15mm. Locking Torque M10 (Nm): 14 - 20 Nm.Temperature Range: –55 to +150 732637326650ml250ml

º

C.

X15-72 LIQUID PTFE

PartCode Unit Size

Recommended for all metal coarse threads up to 76mm diameter. Will seal to burst pressureof the pipe work when fully cured. Ideal for complex systems requiring a slow curing product. Removes the need to over tighten, allowing the perfect alignment of fittings and valves.Diameter-Maximum Gap (mm): 76mm Dia. - 0.3mm. Locking Torque M10 (Nm):5-8Nm. Temperature Range: –55 to +150 73273 7327650ml250ml

º

C.

X15-77 PIPE SEAL

PartCode Unit Size

Use on all metal pipe joints and thread forms up to 76mm diameter. General purpose threadsealant. Replaces all other types of sealing compounds and tapes. Provides a very fast cure even at low temperatures. Can be used on outdoor applications and external plant and equipment.Diameter-Maximum Gap (mm): 76mm Dia. - 0.5mm. Locking Torque M10 (Nm):15-20 Nm. Temperature Range: –55 to +150 73283 7328650ml250ml

º

C.
