LAYOUT INKS

LAYOUT INK SPRAY & FLUID (BLUE/WHITE)

PartCode Unit Size
Rapid drying metal marking inks - which will not crack or flake and are resistant to washing offby water mix cutting fluids. Use for marking out of all metals prior to machining. White for dark surfaces; blue for bright surfaces. 57015 (Blue)57025 (White)57034 (Blue)57044 (White)AerosolAerosol1L1L

SPATTER RELEASE

Designed to prevent the adhesion of molten weld spatter.

SPATTER RELEASE SPRAY

PartCode Unit Size
Non-silicone, heat resistant barrier film. Non corrosive and will not interfere with weldformation. Easily cleaned with a cloth and does not affect subsequent galvanising or painting operations. 66080Aerosol

SPATTER RELEASE FLUID OIL FREE

PartCode Unit Size
Water based spatter release where oil containing products cannot be permitted. Does not affect any subsequent galvanising or painting operations and components can be painted without cleaning 66070 66096500ml5L

WELDMATE SPATTER OFF SPRAY

PartCode Unit Size
Water based spatter release where oil containing products cannot be permitted. Does not affect any subsequent galvanising or paint operations. Components can be painted after wipe-down with a cloth. 66145Aerosol

FLAWFINDER CRACK DETECTION

Non-destructive inspection system designed to provide a fastreliable method for visual detection of cracks or flaws not normally visible to the naked eye.

FLAWFINDER CLEANER SPRAY

PartCode Unit Size
Use to clean areas for inspection and to remove excess penetrant. 63125Aerosol

FLAWFINDER DYE PENETRANT SPRAY

PartCode Unit Size
High sensitivity dye for detecting cracks and flaws under normal light. 63151Aerosol

FLAWFINDER DEVELOPER SPRAY

PartCode Unit Size
A fine white powder film which gives precise definition to the faults highlighted by the dye penetrant. 63135Aerosol

MOULD RELEASE PRODUCTS

Mould release agents offering high performance, economy andversatility in the release of all types of plastic and synthetic rubbers in injection and compression mouldings.

PR SILICONE RELEASE SPRAY

PartCode Unit Size
Wet film silicone release agent. Suitable for blow, flow, injection and compression moulding operations. Suitable up to 200ËšC. 72015Aerosol

MOULD RELEASE SPRAY

PartCode Unit Size
Non-silicone dry film PTFE release agent. Designed for all plastics and rubbers and for moulding parts that will be over printed or painted. Particularly suited for high speed production. Suitable up to 270ËšC. 72021Aerosol

RS7 SPRAY

PartCode Unit Size
Wet film, non-silicone release agent. Particularly suitable for delicate or intricate plastic components. Suitable up to 150ËšC. 72035Aerosol Technical assistance contact: Email: technical.lubricants@rocol.com Tel: +44 (0)113 232 2700 31
