IT Catalogue 2007 - 391 / 476 Pages

Patch panels
482.6 mm (19) installation
Rittal IT catalogue/System accessories 391
Patch panels
To accommodate E-2000,
E-2000 duplex or
SC fibre-optic couplings
For 1 U with accommodation facility for cable
clamp straps DK 7610.000 or DK 7611.000.
Material:
Sheet steel
Colour:
RAL 7035
Accessories:
Cable clamp strap DK 7610.000 or DK 7611.000,
see page 356.
12.4
13.5+0.1
18
30-0.1
22-0.2
2.5 (6 x)
4
9.6+0.1
U
Number of
locations
single/duplex
Model No. DK
1 16/8 7433.035
Other versions available on request.
To accommodate
SCduplex fibre-optic couplings
With accommodation facility for cable clamp
straps DK 7610.000 or DK 7611.000.
Material:
Sheet steel
Colour:
RAL 7035
Accessories:
Cable clamp strap DK 7610.000 or DK 7611.000,
see page 356.
26.42
2.4
30.8
9.91
U Number of
locations Model No. DK
1 12 7154.035
2 24 7155.035
To accommodate
ST fibre-optic couplings
With accommodation facility for cable clamp
straps DK 7610.000 or DK 7611.000.
Material:
Sheet steel
Colour:
RAL 7035
Accessories:
Cable clamp strap DK 7610.000 or DK 7611.000,
see page 356.
9.6+0.1
7.8+0.1
U Number of
locations Model No. DK
1 16 7437.035
2 24 7137.535
2 32 7637.0351)
1) Delivery times available on request.
Other designs available on request.
Identification strips
for patch panels
For individual labelling of different slots,
self-adhesive.
Length: 210 mm, height: 10 mm.
Packs of Model No. DK
32 7167.000
Panel 1 U, 482.6 mm (19)
with solid tray
For the storage of fibre-optic coupling covers or
assembly parts.
Depth: 100 mm
Material:
Sheet steel
Colour:
RAL 7035
U Model No. DK
1 7300.335
