Busbar systems

Accessories Connection pin

Packs of Model No. SV

for OM and OT adaptors/supports

20 9340.280

For the mechanical connection of adaptors and supports. Material: PA 6.6 Colour: RAL 5015

Sliding blocks

Model No. SV

B

for circuit-breaker component adaptor (3-pole)

For With threaded insert Packs of

For additional power circuit breakers with more than two attachment points.

SV 9342.500/.510 SV 9342.540/.550 M3/M46 9342.560

2

.7

SV 9342.600/.610 M4/M56 9342.640
Busbar systems

Support frame

For adaptor width 45 mm

for OM and OT adaptors/supports

For designWidth (B) mmLength (L) mmPacks of Model No. SV

For use as a spare or for the configuration of replacement assemblies. Material: PA 6.6

OM451705 9341.800 OT451955 9341.810 OM/OT452375 9341.820 For adaptor width 55 mm
L For designWidth (B) mmLength (L) mmPacks of Model No. SV
5 OM551705 9341.830 OT551955 9341.840
8 OM/OT552375 9341.850
B

Support frame

Packs of Model No. SV

with fitted sub-unit, for OM and OT Premium adaptors

2 9341.970

To prepare spare assemblies with fully prewired motor starters for OM/OT Premium adaptor (SV9340.900/.910, 9341.900). Connection data of the sub-unit: 3 main contacts (1.5 – 6 mm

2

), 690 V~ 8 auxiliary contacts (0.5 – 2.5 mm

2

), 300 V~ Material: PA 6.6 Supply includes: Sub-unit, pin block, support bar and support frame support.
