Industrial Enclosures

1.6 Stainless steel

Terminal boxes KL see page 25 Compact enclosures AE see page 28 Compact enclosure AE, protection category IP 69K

1)

see page 310 Command Panel housing with door see page 38 Support arm system CP-S see page 313

A

Stand systems see page 317

1

One-piece consoles AP see page 34

.

PC enclosure systems see page 35 Baying systems TS 8 see page 30 Free-standing enclosure ES 5000 see page 32

1)

IP 69K to DIN 40 050-9

Industrial Enclosures

1.6 Keyboard housing, stainless steel

Dimensions in mmNo. of switch cut-outs Model No. SM PageWidthHeightDepthStainless steel 1.4301 (AISI 304)Stainless steel 1.4404 (AISI 316L) 100 100 90 1 2384.010 2384.510
1) 304 160100902 2384.0202384.520
1) 304 220 100 90 3 2384.030 2384.530
1) 304 280100904 2384.0402384.540
1) 304
1) Delivery times available on request.

1.6 Premium Line KL, protection category IP 69K

2)

, stainless steel

Dimensions in mm Model No. KL PageWidthHeightDepthStainless steel 1.4301 (AISI 304)Stainless steel 1.4404 (AISI 316L) 150 150 80 1024.010 1024.510
1) 306 150150120 1024.020 1024.520
1) 306 300 200 120 1024.030 1024.530
1) 306 400300120 1024.040 1024.540
1) 306
1) Delivery times available on request.
2) IP 69K to DIN 40 050-9

1.6 Bus enclosures BG, stainless steel

Dimensions in mm Model No. BG PageWidthHeightDepthStainless steel 1.4301 (AISI 304)Stainless steel 1.4404 (AISI 316L) 200 300 80 1583.010 1583.500
1) 307 20030080 1583.020
1)2) 1583.530
1)2) 307 300 300 80 1584.010 1584.500
1) 30730030080 1584.020
1)2) 1584.530
1)2) 307 400 300 80 1585.010 1585.500
1) 307 40030080 1585.020
1)2) 1585.530
1)2) 307 400 200 123 1558.010 1558.500
1) 307400200123 1558.020
1)2) 1558.530
1)2) 307 600 200 123 1559.010 1559.500
1) 307600200123 1559.020
1)2) 1559.530
1)2) 307
1) Delivery times available on request.
2) With silicone seal.

Approvals (except enclosures with silicone seal): â—� VDE â—� UL â—� TÜV â—� C-UL â—� Lloyds Register of Shipping
