Industrial Enclosures

1.4 Command Panel

based on AE with display panel front Command Panel based on AE with wide VIP 6000 frame

Dimensions in mm Model No. CP PageWidthHeightDepth 380 380 249 6442.500 235 380600249 6462.500 235 500 500 249 6552.500 235 600600249

A

6662.500 235

see page 236.

1

.

Approvals: â—� UL â—� C-UL

Industrial Enclosures

1.4 Support arm systems

Fast selection of CP-S see page 241. Fast selection of CP-L see page 250. Fast selection of CP-XL see page 268. Fast selection of CP-Q see page 280. Support arm system CP-S, stainless steel see page 313.

1.4 Stand systems

Selection see from page 286.

1.5 Compact enclosures HD

Stainless steel

Dimensions in mm Model No. HD PageWidth, single-doorHeight, frontHeight, rearDepthStainless steel 1.4301 (AISI 304)Stainless steel 1.4404 (AISI 316L) 220 350 437 155 1302.600 1302.500
1) 299 390430549210 1306.6001306.500
1) 299 390 650 769 210 1308.600 1308.500
1) 299 510550669210 1307.6001307.500
1) 299 610 430 601 300 1320.600 1320.500
1) 299 610650769210 1310.6001310.500
1) 299 810 1050 1221 300 1316.600 1316.500
1) 299 81012501421300 1317.6001317.500
1) 299
1) Delivery times available on request. 39Rittal Catalogue 32/Industrial Enclosures
