Hygienic Design

Accessories Levelling feet HD

For enclosuresLevelling range mmBase mountPacks of Model No. HD

Material: Stainless steel 1.4301 (AISI304)

TS 8 (M12)120 – 175without4 4000.200

Supply includes:

with4 4000.210

Assembly parts and seals.

Compact enclosures HD120 – 175without2 4000.220

Benefits in detail: The threaded spindle for levelling is completely concealed by a cover, and permanently sealed, thereby eliminating the time-consuming work of cleaning and disinfecting the thread. Option of securing to the

with2 4000.230 Delivery times available on request. To order in stainless steel 1.4404 (AISI 316L) please add the extension .XX1 to the Model No.

B

â—� Enclosure â—� Base/plinth

1

.5

Hygienic Design

Wall spacer bracket HD

Distance from wall mmPacks of Model No. HD

Material: Stainless steel tube 1.4301 (AISI304)

501 4000.100

Supply includes:

1501 4000.110

Assembly parts and seals.

3001 4000.120

Benefits in detail:

Delivery times available on request. To order in stainless steel 1.4404 (AISI 316L) please add the extension .XX1 to the Model No.

Finding a way to permanently and securely seal the enclosure against the wall remains a problem. With this in mind, we recommend that you leave sufficient space to clean behind the enclosure. Depending on the weight and dimensions, one, two, three or four supports may be fitted for attachment purposes. Wall spacer brackets may also be used in cus-tomised designs or with an adaptor plate for mounting other components such as switches and sockets, as well as wire-mesh cable trays.

Enclosure key HD

Packs of Model No. HD

For lock insert HD

1 2549.600 Delivery times available on request.

Bit HD

for universal key SZ 2549.500

Packs of Model No. HD

See page 959.

1 2549.510 Delivery times available on request.

Sloped attachment

for TS 8 For retro-fitting individual or bayed TS 8 enclo-sures of sheet steel, spray-finished, or stainless steel. On request.
