Cable management

Gland plates Metal gland plate

SizeDimensionsPacks of Model No. IN

with grommets Design:

5534 x 149 mm1 2203.030

Protection category: IP 54 to EN 60 529/09.2000 when mounted in the usual position, bottom. 4 inserts each with 8 grommets for cable diameters up to 13 mm. Material: Gland plate: Sheet steel, zinc-plated, passivated, Cable entry grommet: Body: Polypropylene. Cover: Thermoplastic elastomer.

53468.5127127 68.5 1.5

Note:

16.5

The applicable size can be taken from the respective product ordering page.

5591 63.560 149 7 17 1.5

Metal gland plates

SizeCut-out Packs of Model No. KL

Material:

2Without6 1158.500

Sheet steel, spray-finished

21 x connector, 16-pole6 1158.560

Colour: RAL 7035

21 x connector, 24-pole6 1158.540

Note:

23 x module plates6 1158.530

The applicable size can be taken from the respective product ordering page. Accessories: Module plates for individual cable entry, see page 1051. KL 1158.500 KL 1158.530

1

16-pole

202221 202221 32 36 M4 10386 7290 76 76 7290 2
112130

24-pole

Ø 4.5 Ø 4.5 32 36 M4 1

KL 1158.560 KL 1158.540

2

Module plates

for individual cable entry

Fig.DesignMaterialPacks of Model No. BG
Gland plates With connector grommet for 2 cables with connectors up to d = 8.5mmModule plate: Sheet steel, zinc-plated, passivated Connector gland: (For details, see SZ 2400.300, page 1057)1 1158.900 1 Punched for metric cable glandM25Sheet steel, zinc-plated, passivated10 1158.910 Solid 1158.930 1 2 2 For direct, IP-protected insertion of sensor/ actuator cables2 + 2 3
1)

B

Plastic module plate with strain relief and flexible sealing membrane, including stoppers for any unused openings1 1158.940 4 8
2) 1158.950

7

.8

To fit Ø
1) 2 cables from 6.8 to 8.8 mm and 2 cables from 7.8 to 10.7 mm
2) 8 cables from 3.8 to 6.3 mm 3 4 1051Rittal Catalogue 32/System accessories
