1400
High performance semiautomatic strapping machine. Electronicadjustment of tension, heating and length of the strap. ·Designed and manufactured using highest quality components.·Aluminium head set and tension roller treated ensure long life of the machine.·Tension electronically adjustable through a magnetic clutch to get the strongest tension without any physical effort.·Electronic control of the tension, heating, cutting and length of the strap.·Electric adjustment of the cooling after sealing to get better sealing quality, especially for hard packages (wood, iron, etc).·Light and easy to move because of its lockable castors.
The 1400 is light and easyto move because of itslockable castors.Detail of the 1400 electroniccontrol panel.
CHARACTERISTICS
VOLTAGE: 220 / 240 V · 50 / 60 Hz. Single phase.ELECTRIC CONSUMPTION: 0,5 Kw.APROX. PRODUCTION: 15-20 packages / minute.PACKAGING DIMENSIONS: 1 package (75 Kg.).64 X 94 X 93 cm.
905 580
465325
TECHNICAL SPECIFICATIONS
455215120
790
STRAP WIDTH: 6-8-12-15,5 mm. (factory set).STRAP THICKNESS: 0,50-0,85 mm.HEATING SYSTEM: Electrical heating.Heating temperature and cooling time adjustable.OPTIONS: Semi-arch.
85 Semiautomatic
strapping machine 01/04 Edition ·We reserve the right to made any modification without prevention.
Reisopack s.l.
1400
Polígono Industrial “Z”C/ De la Premsa, 3
08150 Parets del Vallès (Spain)Tel. 902 153 448 · Fax 935 624 186http: //www.reisopack.com
