INDICATORS

INDICATOR 2100

Display : digital Segments : LCD, height 18 mm Graduation : 0.1, 0.2, 0.5, 1, 2, 5, 10, 20 or 50 kg see specifications weighing system Functions : manual and automatic zero correction gross/net weighing automatic tare by push button manual tare entry by cursor function totaling with sequence number error indication in display printer power supply is switched on and off by the indicator Housing : steel / plastic (ABS) Colour : red (RAL 3000) Protection class : IP65 Power supply : 12V/1,2 Ah battery for mobile applications : indicator switches off automatically when voltage is too low or after 30 minutes of non-use : 230V for stationary applications Power consumption : 41 mA on 6 volt 18 mA on 12 volt Dimensions : excl. bracket: 60 x 77 x 182 mm Options : multirange (see specifications weighing system) explosion proof version (EXi) thermal or matrix printer (internal or external) output RS232 automatic and manual zero correction

INDICATOR 4100

gross/net weighing Display : digital Segments : LCD, height 18 mm, backlight Graduation : 0.1, 0.2, 0.5, 1, 2, 5, 10, 20 or 50 kg see specifications weighing system Functions : automatic tare by push button manual tare entry by cursor function totaling with sequence number error indication in display piece counting by sampling piece counting by entering piece weights code entry for max. 6-digit codes by cursor functions kg / lb toggle internal clock (for recording date/time on printout) printer power supply is switched on and off by the indicator Housing : steel / plastic (ABS) Colour : red (RAL 3000) Protection class : IP65 Power supply : 12V/1,2 Ah battery for mobile applications : low voltage indication in display : automatic switch-off after 30 minutes of non-use : 230V for stationary applications Power consumption : 62 mA on 6 volt (42mA without backlight) 26 mA on 12 volt (18mA without backlight) Dimensions : excl. bracket: 60 x 77 x 182 mm Options : multirange (see specifications weighing system) explosion proof version (EXd) thermal or matrix printer (internal or external) relay output bluetooth data transfer output RS232, for connection to printer or PC data communication Approved version : memory for last 10 entered tare values, codes and piece weights : no kg / lb toggle, no backlight and no piece counting by sampling : specifications can differ from standard specifications
