Signal lamps with integrated LED
Signal lamps with integrated LED, 5 mm, protruding LED
Pict.: redMounting hole Integrated currencyresistor Operating voltage U B Forward current, I Lamp Colour of lens Order no. F at 25°C no according to seriesresistor 5 - 28 V max. 20 mA LED red transparent red 1.69.508.801/0000 no according to series
resistor 5 - 28 V max. 20 mA LED green transparent green 1.69.508.807/0000 no according to series
resistor 5 - 28 V max. 20 mA LED yellow transparent yellow 1.69.508.813/0000 yes 24 - 28 V 8 - 12 mA LED red transparent red 1.69.508.804/0000 yes 24 - 28 V 8 - 12 mA LED green transparent green 1.69.508.810/0000 yes 24 - 28 V 8 - 12 mA LED yellow transparent yellow 1.69.508.816/0000
Technical data see page 3 - 6 Long terminal is anode. 3
Integr.LED Signal lamps3 - 7
Stock items are markedby bold printed order numbers.
