Signal lamps with lamp socket
Signal lamps with lamp socket E 10 (MES), 16.2 mm
Electrical characteristics Voltage limit max.250 VPower limit max.2 W Other specifications Degree of protection
from front sideIP40
Weight11 g
Approvals at 2W
(T=°C)VDE
Panel cut-outScrew terminals, yellowPict.: red Technical data
General information Form of lensround
Colour of lenssee order block
Diameter of collar20 mm Dimensions Overall heightsee order block
Mounting depthsee order block
Mounting hole16.2 mm Mechanical design Mountingring nut
Terminalssee order block
Lamp socketE 10
Lampfilament lamp
3
Accessories Signal lamps with lamp socket E 10 (MES), 16.2 mm
Description Photo Order no. Page WithSocket Filament lamp, E 10 (MES) base, 24 - 30 V 1.90.010.033/0000 5 - 11 Filament lamp, E 10 (MES) base, 110 - 130 V 1.90.010.037/0000 5 - 11 Protective sleeve for terminals 5.52.011.026/0100 Fixing spanner M 15, M 16 5.58.002.019/0105 5 - 25
3 - 44Signal lamps
Stock items are markedby bold printed order numbers.
