Text version of the page
table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:5.00pt "Arial", sans-serif; } .font1 { font:6.00pt "Arial", sans-serif; } .font2 { font:7.00pt "Arial", sans-serif; } .font3 { font:8.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Arial", sans-serif; } .font5 { font:13.00pt "Arial", sans-serif; } .font6 { font:30.00pt "Arial", sans-serif; } Signal lamps with lamp socket S gnal lamps with lamp socket BA 9s MBC/MCC), 16.2 mm, round lens Panel cut-out Pict.: colourless Voltage limit max. Power limit max. Degree of protection from front side Colour of lens Order no. complete Order no. single parts Housing Lens 250 V 2 W IP40 transparent colourless 1.63.004.001/1002 1.63.004.091/0000 5.49.205.013/1002 250 V 2 W IP40 transparent red 1.63.004.001/1301 1.63.004.091/0000 5.49.205.013/1301 250 V 2 W IP40 transparent yellow 1.63.004.001/1402 1.63.004.091/0000 5.49.205.013/1402 250 V 2 W IP40 transparent green 1.63.004.001/1502 1.63.004.091/0000 5.49.205.013/1502 Technical data see page 3 - 42 Accessories: Filament lamp, BA 9s base (MBC/MCC), 12 - 15 V: 1.90.060.132/0000 Filament lamp, BA 9s base (MBC/MCC), 24 - 30 V: 1.90.060.133/0000 Filament lamp, BA 9s base (MBC/MCC), 110 - 130 V: 1.90.060.137/0000 3 S gnal lamps with lamp socket BA 9s MBC/MCC), 16.2 mm, round lens With Socket Pict.: yellow Panel cut-out Voltage limit max. Power limit max. Degree of protection from front side Colour of lens Order no. complete Order no. single parts Housing Lens 250 V 2 W IP65 transparent colourless 1.63.004.010/1002 1.63.004.100/0000 5.49.227.007/1002 250 V 2 W IP65 transparent red 1.63.004.010/1301 1.63.004.100/0000 5.49.227.007/1301 250 V 2 W IP65 transparent yellow 1.63.004.010/1402 1.63.004.100/0000 5.49.227.007/1402 250 V 2 W IP65 transparent green 1.63.004.010/1502 1.63.004.100/0000 5.49.227.007/1502 Technical data see page 3 - 42 Accessories: Filament lamp, BA 9s base (MBC/MCC), 12 - 15 V: 1.90.060.003/0000 Filament lamp, BA 9s base (MBC/MCC), 24 - 30 V: 1.90.060.014/0000 Signal lamps Stock items are marked by bold printed order numbers. 3 - 43
