Signal lamps with lamp socket
Signal lamps with lamp socket T 4.6, 9.1 mm
Electrical characteristics Voltage limit max.42 VPower limit max.1 W Other specifications Degree of protection
from front sideIP40
Weight1 g
Mounting holecolourlessPict.: red Technical data
General information Form of lenssee order block
Colour of lenssee order block
Diameter of collar11 mm Dimensions Overall heightsee order block
Mounting depth30.5 mm
Mounting hole9.1 mm Mechanical design Mountingring nut
Terminalssolder terminals
Lamp socketT 4.6
Lampfilament lamp
3
Accessories Signal lamps with lamp socket T 4.6, 9.1 mm
Description Photo Order no. Page WithSocket Filament lamp, T 4.6 base, 12 V 1.90.100.012/0000 5 - 6 Filament lamp, T 4.6 base, 24 V 1.90.100.013/0000 5 - 6 Fixing spanner M 9, M 10 5.58.002.025/0105 5 - 25
3 - 38Signal lamps
Stock items are markedby bold printed order numbers.
