Signal lamps with lamp socket
Signal lamps with lamp socket W 2 x 4.6d, 9.1 mm
Electrical characteristics Voltage limit max.42 VPower limit max.1.2 W Other specifications Degree of protection
from front sideIP40
Weight1 g
Mounting holePict.: red Technical data
General information Form of lensround
Colour of lenssee order block
Diameter of collar11 mm Dimensions Overall height7 mm
Mounting depth25.5 mm
Mounting hole9.1 mm Mechanical design Mountingring nut
Terminalsquick connector A 2.8 x 0.5 tin-platedLamp socketW 2 x 4.6d
Lampfilament lamp
3
Accessories Signal lamps with lamp socket W 2 x 4.6d, 9.1 mm
WithSocket Description Photo Order no. Page Filament lamp, W 2 x 4.6d base, 24 - 30 V 1.90.120.005/0000 5 - 4 Filament lamp, W 2 x 4.6d base, 60 V 1.90.120.009/0000 5 - 4 Filament lamp, W 2 x 4.6d base, 48 V 1.90.120.010/0000 5 - 4 Filament lamp, W 2 x 4.6d base, 24 V 1.90.120.011/0000 5 - 4 Filament lamp, W 2 x 4.6d base, 12 V 1.90.120.012/0000 5 - 4 Filament lamp, W 2 x 4.6d base, 6 V 1.90.120.013/0000 5 - 4 Protective sleeve made of Buna N (NBR), 7 x 30 5.52.011.022/0100 Fixing spanner M 9, M 10 5.58.002.025/0105 5 - 25
3 - 36Signal lamps
Stock items are markedby bold printed order numbers.
